Ersa tip holders


            The tip holders SMD 8013, SMD 8014 and SMD 8015
            are equipped with the latest soldering tips or desoldering
            tip pairs, in particular for SMD techno logy. Tips can be stored
            neatly arranged in a space-saving way for quick access.
            The range of soldering tips and desoldering tip pairs with the
            component-specific dimensions can be found on pages 38,
            39, 42, 43 and 46.                                                                                        i-CON soldering/desoldering stations
            All soldering tips and desoldering tip pairs are manufactured
            according to the ERSADUR process. They have excellent
            thermal conductance and a long service life.



























            SH 03                                              SMD 8013
            tip holder, unequipped                             tip holder, complete
























            SMD 8014                                           SMD 8015
            tip holder, complete                               Tip holder 0SH11 with adapter



            Order no.  Description                  Equipped with                       Equipped with
                                                    ERSADUR soldering tips              ERSADUR desoldering tips
            0SH03    tip holder SH 03, unequipped   none                                none
            0SMD8013  tip holder SMD 8013, complete  0212BDLF, …CDLF, …EDLF, …FDLF, …SDLF,  0422ED, …MD, …SD, 0452FDLF100,
                                                    0212MS, …GD, …WD                    …FDLF125, …FDLF150, …FDLF175,
                                                                                        …FDLF200, …QDLF100, …QDLF175
            0SMD8014  tip holder SMD 8014, complete  0102PDLF04, …PDLF10, …CDLF12, …CDLF16,   0422SD, 0452EDLF060, …FDLF100,
                                                    …WDLF16, …WDLF23, …BDLF20 and       …FDLF150, …MDLF020, …QDLF100,
                                                    tip fastener 3IT1045-00 (green version)   …QDLF175
                                                    for i-TOOL, complete
            0SMD8015  tip holder SMD 8015, complete  0102PDLF04, …PDLF10, …CDLF24, …WDLF23, …ADLF40,   0742ED0819H, ...1023H, ...1225H,
                                                    ...SDLF06L and tip fastener 3IT1045-00 (green version)   0462SDLF002 and 0462CDLF018,
                                                    for i-TOOL, complete                0472BR, ...CR, ...DR and ...ER
