Ersa i-CON VARIO 4 multi-channel station

PTC

i-CON VARIO 4 i-CON soldering/desoldering stations
Antistatic multi-channel soldering and desoldering station
with i-TOOL AIR S hot-air iron, CHIP TOOL VARIO desoldering
tweezers, X-TOOL VARIO desoldering iron, i-TOOL HP high-
performance soldering iron and i-TOOL soldering iron.
Order no. 0ICV4000AICXV

The i-CON VARIO 4 multi-channel soldering and desoldering station meets high-
est demands in the field of professional soldering and desoldering. It is the i-CON
family’s flagship. The user can connect and operate up to 4 tools at the same time:
the ergonomic i-TOOL AIR S hot-air iron with 200 W for flexible soldering and desol-
dering with non-contact energy transfer; the i-TOOL with 150 W for efficient solder-
ing; the 250 W i-TOOL HP for demanding high-mass applications, the new CHIP TOOL
VARIO with 80 W for precise desoldering of most delicate SMDs and the X-TOOL
VARIO with 150 W for desoldering through-hole components. Alternatively the i-CON
VARIO 4 can operate further Ersa soldering tools.
All functions, including air and vacuum units, are integrated in the central supply
unit featuring Ersa’s well-known iOp operation and clearly arranged displays. Fur-
thermore the station has interfaces to connect Ersa solder fume extraction units
or infrared heating plates as well as a USB port. The configuration of the station
is quick and easy via microSD card leaving it optimally prepared for all applications
in professional electronics production. The i-CON VARIO 4 is perfectly suited for
the use in ESD protected zones.
Order no. Description Rating/voltage Vacuum Air flow Temperature range Weight
(w/o cable)
0ICV403A i-CON VARIO 4 max. 500 W/230 V, 50 Hz max. 700 mbar 2 – 20 l/min 50 – 450 °C
1ICV403A00A67 electronic station max. 500 W/115 V, 60 Hz (50 – 550 °C – i-TOOL AIR S)
0ICV203A i-CON VARIO 2 max. 200 W/230 V, 50 Hz 2 – 20 l/min 50 – 450 °C
1ICV203A00A67 electronic station max. 200 W/115 V, 60 Hz (50 – 550 °C – i-TOOL AIR S)
0ICV203AP i-CON VARIO 2 max. 200 W/230 V, 50 Hz max. 700 mbar 2 – 20 l/min 50 – 450 °C
1ICV203AP1A67 electronic station max. 200 W/115 V, 60 Hz (50 – 550 °C – i-TOOL AIR S)
0ICV203HP i-CON VARIO 2 max. 200 W/230 V, 50 Hz 50 – 450 °C
1ICV203HP0A67 electronic station max. 200 W/115 V, 60 Hz
0470ERJ i-TOOL AIR S 200 W 50 – 550 °C approx. 90 g
hot-air iron
0100CDJ i-TOOL 150 W 50 – 450 °C approx. 30 g
soldering iron
0240CDJ i-TOOL HP 250 W 150 – 450 °C approx. 110 g
soldering iron
0460MDJ CHIP TOOL VARIO 2 x 40 W 150 – 450 °C approx. 75 g
desoldering tweezers
0740EDJ X-TOOL VARIO 150 W 150 – 450 °C approx. 210 g
desoldering iron
0ICV207 VARIO TOOL ADAPTER
to plug the i-TOOL, X-TOOL VARIO or CHIP TOOL VARIO into socket A2 of the electronic station

Contents/order no. 0ICV2000A 0ICV2000AI 0ICV2000AC 0ICV2000AXV 0ICV2000HP 0ICV4000A 0ICV4000AI 0ICV4000AIC 0ICV4000AICXV
i-TOOL AIR S
i-TOOL

i-TOOL HP
CHIP TOOL VARIO

X-TOOL VARIO
