P. 24
Hybrid rework systems Ersa HR 100 hybrid rework system
Rapid, simple and safe hand-held
component removal
HR 100 (0IRHR100A-HP)
with HYBRID TOOL, VAC-PEN vacuum pipette, 3 hybrid adapters, adapter changer, tool
stand for HYBRID TOOL and IR heating plate with PCB holder
Figure with optional thermocouple and stand
The HR 100 uses Ersa’s patented Hybrid Rework Technology non-experienced operators to han-
for safe removal and replacement of components sizing from dle the HR 100 safely and quickly. Ad-
0201 chips to 20 x 20 mm SMDs. Safe, medium-wave IR radi- vanced operators using the complete
ation combined with a gentle hot air stream guarantees opti- system can not only set air volume
mal energy transfer to the component. Exchangeable hybrid and heating power levels, but they can
adapters focus 200 W of safe hybrid heating power onto the also run and record profiles with the
component while protecting neighboring areas from blow- IRSoft rework software!
ing away adjacent chips. The HYBRID TOOL handle contains a
positioning laser. The user-friendly operation allows for even Temperature-controlled SMD soldering
Ersa HR 200 – Rework out of the Box!
Unpack, setup, solder! It´s as simple as that to rework a PCB
nowadays. The Ersa HR 200 hybrid rework system contains
a 400 W hybrid highpower heating element to desolder and
solder SMT components up to 30 x 30 mm. As an option, the
system can operate a powerful 800 W infrared heating plate.
This bottom heater guarantees ideal preheating of the as-
sembly to rework.
The operator selects the required power for top and bot-
tom heating with a control knob, each with four levels. A foot HR 200 (0HR200-HP)
switch activates the heating process. The operator’s hands
are free to remove the desoldered component with appropri- Hybrid rework system with
ate tools. IR heating plate and PCB
holder
Figure without foot switch
Order no. Description Rating/voltage Heated area Weight
(w/o cable)
0IRHR100A HR 100 hybrid rework system, complete, 200 W/230 V, 50 – 60 Hz
with HYBRID TOOL 3IRHR100A-01, 6 x 6 mm to 300 g
VAC-PEN vacuum pipette 0VP020, 20 x 20 mm
hybrid adapters 0IRHR100A-14, -15, -16 and adapter changer 0IRHR100A-24
1IRHR100A0A67 200 W/115 V, 50 – 60 Hz
0IRHR100A-HP HR 100 hybrid rework system, complete, 200 W/230 V, 50 – 60 Hz
with HYBRID TOOL 3IRHR100A-01, VAC-PEN vacuum pipette 0VP020, 6 x 6 mm to 300 g
three hybrid adapters, adapter changer, HYBRID TOOL holder and 20 x 20 mm
IR heating plate with PCB holder 800 W/230 V, 50 – 60 Hz 125 x 125 mm 2.5 kg
1IRHR100AHPA67 200 W, 800 W/115 V, 50 – 60 Hz
Recommended accessories for 0IRHR100A:
0IRHR-ST050 Hybrid rework tripod, complete
0HR200 HR 200 hybrid rework system with foot switch, positioning laser 400 W/230 V, 50 – 60 Hz 30 x 30 mm 3.7 kg
and PCB holder
1HR2000000A67 400 W/115 V, 50 – 60 Hz
0HR200-HP HR 200 hybrid rework system with foot switch, positioning laser, 400 W/230 V, 50 – 60 Hz 30 x 30 mm 3.7 kg
PCB holder and heating plate 800 W/230 V, 50 – 60 Hz 125 x 125 mm 1.6 kg
1HR200-HP0A67 400 W, 800 W/115 V, 50 – 60 Hz
24 For detailed information on these rework systems and further rework products please refer to the Ersa catalog “Ersa Rework and Inspection Systems”.
