Volume fume extraction

Zero Smog TL Kit 1 FN

Fume extraction unit with flexible extraction arm,
extraction hose, stop valve with bench mounting
brackets, remote switch and funnel nozzle

120 W

LOW
SOUND < 50 db (A)
LEVEL

Order No. FT91 01 569 9N

Scope of supply Order No. Model Description
0F10 0F10 flexible Easy-Click 60 flexible Extraction arm, Ø 60 mm for sloped and
Extraction arm funnel nozzles, length 1 m
700-3051-ESD Extraction hose Easy-Click 60 Extraction hose Ø 60 mm, length: 3 meter
3 meter
ALFA ALFA Funnel Nozzle Easy-Click 60 Funnel nozzle, for flexible and stativ extraction arm,
width 230 mm, height 100 mm. To be mounted on an aluminium
extraction arm without flexible hose, adapter Z is needed. See
extraction arms accessories.
FT910 00 033 On-/Off-Switch ZSRS Zero Smog Remote Switch
FT910 13 699 N Zero Smog TL Fume extraction unit Zero Smog TL

Zero Smog TL Kit 2 FN

Fume extraction unit with 2 flexible extraction
arms, 2 fixing clamps for the arms, a
remote switch and 2 funnel nozzles

120 W
LOW
SOUND < 50 db (A)
LEVEL

Order No. FT91 01 769 9N

Scope of supply Order No. Model Description
0F15 0F15 Flexible Extraction arm, flexible, Ø 60 mm for sloped and funnel nozzles,
extraction arm length 1,5 m
ALFA ALFA Funnel Nozzle Easy-Click 60 Funnel nozzle, for flexible and stativ extraction arm,
width 230 mm, height 100 mm. To be mounted on an aluminium
extraction arm without flexible hose, adapter Z is needed. See
extraction arms accessories.
FT910 00 033 On-/Off-Switch ZSRS Zero Smog Remote Switch
FT910 13 699 N Zero Smog TL Fume extraction unit Zero Smog TL
T005 87 628 46 Fixing clamp Fixing clamp Ø 63 mm, 1 piece, for fixing Easy-Click 60, 60 mm
extraction arms
