ACCESSORIES

Hot Air Tools

TMT-HA050 ESD LEAD
ESD
LEAD
SAFE
FREE
SAFE
FREE
The TMT-HA050 hot air tool can be used for the
removal of surface mount components such as
SOIC, QFP, PLCC and other similar devices.
Digital display shows temperature and air flow
Light, portable, plug and use tool
Uses HTN Series Hot Air Nozzles
Convection heating allowing low pressure hot air
to focus on the solder joints

TMT-HA050 SPECIFICATIONS PACKING LIST

Input Line Voltage: 220-240 VAC TMT-HA050 Hot Air Tool
Power: 600 Watts HTN-D30 Nozzle 3.0mm (0.12")
Temperature Range: 100 °C - 480 °C HTN-D50 Nozzle 5.0mm (0.20")
Pump: Turbine Motor HTN-D80 Nozzle 8.0mm (0.31")
Airflow (Max): 30L / min HTN-D100 Nozzle 10.0mm (0.39")
Fuse: 250V 3A HA-HE050 Heating Element
Size (W x H x D): 65mm x 265mm CERTIFICATION
Weight: 1 KG
MARK

TMT-HA200 ESD LEAD
ESD
LEAD
SAFE
FREE
SAFE
FREE
The TMT-HA200 hot air tool can be used for the
removal and reflow of surface mount components
such as SOIC, QFP PLCC and other similar devices.
Large selection of high quality nozzles
Adjustable, easy to use temp and air control knobs
Uses HTN Series Hot Air Nozzles
Auto sleep activated when hot air tool is placed in
the holder.

TMT-HA200 SPECIFICATIONS PACKING LIST

Input Line Voltage: 220-240 VAC TMT-HA200 Hot Air Tool
Power: 600 Watts HTN-D30 Nozzle 3.0mm (0.12")
Temperature Range: 100 °C - 480 °C HTN-D50 Nozzle 5.0mm (0.20")
Pump: Turbine Fan HTN-D80 Nozzle 8.0mm (0.31")
Airflow (Max): 35L / min HTN-D100 Nozzle 10.0mm (0.39")
Fuse: 250V 3A HA-HE200 Heating Element
Size (W x H x D): 112mm x 205mm x 117mm CERTIFICATION
Weight: 2.40 KG
MARK
