DS-KIT

Desoldering Kit

DS-KIT ESD LEAD
ESD
LEAD
SAFE
FREE
SAFE
FREE
Thermaltronics DS-KIT desoldering kit uses
shop air to create a powerful air vacuum to clean
through-holes quickly and efficiently. Cleaning and
maintenance is quick and easy with the use of
replaceable filter wools (DS-FW-1) and chamber
liners (DS-CL-1).
Uses Thermaltronics DT Series Desoldering Tips.
High thermal recovery & performance.
Easy and simple maintenance.

DESOLDERING KIT INCLUDES
DS-KIT-1* DS-KIT-2* DS-KIT-3*
Desoldering Gun Airhose DS-AH-1 DS-AH-1 DS-AH-1
Filter Wool (6 pairs) & Chamber Liner (15 pcs) DS-CP-1 DS-CP-1 DS-CP-1
Desoldering Gun DS-GUN-1 DS-GUN-2 DS-GUN-3
Desoldering Gun Handpiece Cable DS-HPC-1 DS-HPC-2 DS-HPC-3
Cleaning Toolkit DS-TCT-1 DS-TCT-1 DS-TCT-1
Cartridge Removal Pad RMP-1 RMP-1 RMP-1
Desoldering Gun Workstand SHH-3 SHH-3 SHH-3
*DS-KIT-1 for use on TMT-9000S, DS-KIT-2 for use on TMT-5000S, DS-KIT-3 for use on TMT-2000S

DESOLDERING TIPS
TMT-5000S B C
Part Number MM IN. MM IN.
C C T75DT003 0.80 0.03" 13.00 0.51"
T75DT003L 0.80 0.03” 18.00 0.71"
T75DT004 1.10 0.04" 13.00 0.51"
T75DT004L 1.10 0.04" 18.00 0.71"
T75DT005 1.35 0.05" 13.00 0.51"
B B T75DT005L 1.35 0.05" 18.00 0.71"
T75DT006 1.50 0.06" 13.00 0.51"
STANDARD LONG REACH (L) T75DT007 2.40 0.095" 13.00 0.51"

TMT-9000S B C TMT-2000S B C
Part Number MM IN. MM IN. Part Number MM IN. MM IN.
M80DT003 0.80 0.03" 13.00 0.51" K60DT003 0.80 0.03" 13.00 0.51"
M80DT003L 0.80 0.03" 18.00 0.71" K60DT003L 0.80 0.03" 18.00 0.71"
M80DT004 1.10 0.04" 13.00 0.51" K60DT004 1.10 0.04" 13.00 0.51"
M80DT004L 1.10 0.04" 18.00 0.71" K60DT004L 1.10 0.04" 18.00 0.71"
M80DT005 1.35 0.05" 13.00 0.51" K60DT005 1.35 0.05" 13.00 0.51"
M80DT005L 1.35 0.05" 18.00 0.71" K60DT005L 1.35 0.05" 18.00 0.71"
M80DT006 1.50 0.06" 13.00 0.51" K60DT006 1.50 0.06" 13.00 0.51"
M80DT007 2.40 0.095" 13.00 0.51" K60DT007 2.40 0.095" 13.00 0.51"
