ACCESSORIES

Hot Air Tools

TMT-HA300 ESD LEAD
ESD
LEAD
SAFE
SAFE
FREE
FREE
The TMT-HA300 hot air tool uses a large diaphragm
pump and can be used for the removal and reflow
of surface mount components such as SOIC, QFP,
PLCC and other similar devices.
Digital display shows temperature and status.
Airflow meter provides visual feedback of air flow.
Adjustable, easy to use temp and air control knobs
Uses HTN Series Hot Air Nozzles

TMT-HA300 SPECIFICATIONS PACKING LIST

Input Line TMT-HA300-1 100-110 VAC TMT-HA300 Hot Air Tool
Voltage:
TMT-HA300 220-240 VAC HTN-D30 Nozzle 3.0mm (0.12")
Power: 500 Watts HTN-D50 Nozzle 5.0mm (0.20")
Temperature Range: 100 °C - 480 °C HTN-D80 Nozzle 8.0mm (0.31")
Pump: Diaphragm Pump
HTN-D100 Nozzle 10.0mm (0.39")
Airflow (Max): 23L / min
HA-HE300 Heating Element
Fuse: TMT-HA300-1 250V 5A
TMT-HA300 250V 3A CERTIFICATION
Size (W x H x D): 188mm x 127mm x 246mm MARK
Weight: 3.00 KG

TMT-HA600 ESD LEAD
ESD
LEAD
SAFE FREE
SAFE
FREE
The TMT-HA600 hot air tool uses a large diaphragm
pump and a high power 1300W heater, designed to
work on more difficult applications, in the removal
and reflow of surface mount components.
Fast heating and temperature recovery
Simple controls allow easy adjustment.
Uses HTN Series Hot Air Nozzles
Digital display with easy-to-adjust temp and airflow

TMT-HA600 SPECIFICATIONS PACKING LIST

Input Line TMT-HA600-1 100-110 VAC TMT-HA600 Hot Air Tool
Voltage:
TMT-HA600-2 220-240 VAC HTN-D50 Nozzle 5.0mm (0.20")
Power: 1300 Watts HTN-D80 Nozzle 8.0mm (0.31")
Temperature Range: 100 °C - 480 °C HTN-D100 Nozzle 10.0mm (0.39")
Pump: Diaphragm Pump
HTN-D120 Nozzle 12.0mm (0.47")
Airflow (Max): 23L / min
HA-HE600 Heating Element
Fuse: TMT-HA600-1 250V 15A
TMT-HA600-2 250V 8A CERTIFICATION
Size (W x H x D): 188mm x 127mm x 246mm MARK
Weight: 3.00 KG www.thermaltronics.com
