SUPERFORM-A SUPERFORM/A is a machine made for cu ng and bending axial taped components,

it is extremely compact and sturdy and its main characteris c is to form components
with rheophore up to 1.4 mm. Its tracking wheels are adjustable independently to
allow rapid setup at different forms.

Produc on rate: up to 40000 pcs/hr
7915.030 Motor unit for SUPERFORM, 230V - 50/60Hz
7915.031 Motor unit for SUPERFORM, 115V - 50/60Hz
7915.180 CS10 feeder for loose axial components
7915.185 Tape reel holder arm BR6

B P C D d L
version quick setting
Min. Max. Min. Max. Min. Max. Min. Max. Max.
7915.100 A standard model 4 13 6.5 60 (40*) 1.2 16 0.4 1.3 50 7915.100AR
7915.100 D reinforced bending knives 5 13 105 60 (40*) 2.4 16 0.6 1.4 50 7915.100DR
reduced cutting length
7915.100 F reduced bending length 4 13 5 60 (40*) 0.8 10 0.4 0.8 50 7915.100FR
7915.100 G like"F" + fi xed pitch 4 10 5 - 0.5 4 0.4 0.6 3.5 -
(*) maximum P dimension with quick se ng
SUPERFORM-AP SUPERFORM/AP is a machine made for cu ng and bending axial taped components

for ver cal assembling, and shaping a li le curl on each lead. The machine handles wire
diameters ranging from 1 mm to 1.4mm.

By replacing the 2 “cu ng/forming wheels” with 2 “only cu ng wheels” (op onal)

it is possible to obtain an U-shape without curls.
Produc on rate: up to 20000 pcs/hr

7915.030 Motor unit for SUPERFORM, 230V - 50/60Hz
7915.031 Motor unit for SUPERFORM, 115V - 50/60Hz
7915.180 CS10 feeder for loose axial components
7915.185 Tape reel holder arm BR6
Z P B C L d D h
Mod. version
Fix. Min. Max. Min. Max. Min. Max. Max. Min. Max. Max. Min. Max.
7915.102A standard model 3.1 6.5 60 1.2 1.3
7915.102B reinforced bending knives 3.1 10.2 60 2.4 1.4
7915.102C standard model 3.9 6.5 60 1.2 1.3
10 14 10 50 1 16 7 11
7915.102D reinforced bending knives 3.9 10.2 60 2.4 1.4
7915.102E standard model 5 6.5 60 1.2 1.3
7915.102F reinforced bending knives 5 10.2 60 2.4 1.4

OPTIONAL ACCESSORIES

SUPERFORM MOTOR UNIT

Equipped with manual speed adjustment and automa c torque
control for an easy and fast working of the SUPERFORM machine.
The motor unit is supplied only with the machine assembled.
7915.030 M230V Motor Unit for SUPERFORM/A-AP-S-V-R-RCP
7915.031 115V Motor Unit for SUPERFORM/A-AP-S-V-R-RCP
7915.032 230V Motor Unit for SUPERFORM/AF-VP
7915.033 115V Motor Unit for SUPERFORM/AF-VP
600.023 Foot switch for 7915.030/031/032/033 motors
SUPERFORM Tape Reel Holder BR6

A tape reel holder arm to be fixed on the le side of Superform,

BR6
to facilitate unwinding of the tape. BR6
7815.185 BR6 for all SUPERFORM models
