SUPERCUT-LN5 This pneuma c machine is designed to cut/trim almost

every type radial lead components.

The guillo ne cu ng system, with zero clearance between

the plates, guarantees a sharp and precise cut without
burrs or damage to the leads.

It is possible to cut many components at the same me
without any risk of wear of the blades.

The machine can be supplied with special cu ng jig.

An addi onal op onal plate (thickness to be specified , max

3mm) can be supplied to increase the cu ng height of the

leads.

Two models available, the first with a cu ng area 53x43mm,

TECHNICAL FEATURES the second with a cu ng area 53x93mm.
Produc on rate: up to 3000 pcs/hr

Dimensions (7915.041): 100 x 250 x 93 mm
Dimensions (7915.041L): 100 x 300 x 93 mm
Supply: 6 ATM
Weight: 4,5/6 Kg
L d
Min. (mm) 0.3
Max. (mm) 1.3
Fix. 3.2
7915.041 SUPERCUT/LN5 with foot pedal control
7915.041L SUPERCUT/LN5L long model with foot pedal control

340.114 Op onal addi onal plate for SUPERCUT/LN5
(max 3mm)
340.214 Op onal addi onal plate for SUPERCUT/LN5L

(max 3mm)
Standard plate hole layout Standard plate hole layout
SUPERCUT/LN5 SUPERCUT/LN5L

SUPERFORM-V P d A D

fi x. min. max. min. max. max.
7915.101 B 2.54 0.5 0.8 2 6 3
standard
7915.101 C 3.8 0.5 0.8 2.5 5 5
7915.101 D 5.08 0.5 0.8 3 7 8
7915.101 E 7.62 0.5 0.8 4 7 10
7915.091 A 3.8 0.8 1.3 4 9 5
7915.091 B 5.08 0.8 1.3 5 9 8
7915.091 C 7.62 0.8 1.3 6 9 10
SUPERFORM/V is a machine made for cutting and
bending axial taped components for ver cal moun ng.

Produc on rate up to 40000 pcs/hr
7915.030 Motor Unit for SUPERFORM, 230V - 50/60Hz
7915.031 Motor Unit for SUPERFORM, 115V - 50/60Hz
7915.182 Feeder CS30 for loose axial components
7915.185 Tape Reel Holder arm BR6
