Simple and easy to use
for rework technicians or
operators on the line.

MBT 301

The MBT 301 is a multi-technology system with two, individually
controlled, universal handpiece channels. The system features a
two-line back lit LCD display. The programmable features include:
password protection from unauthorized changes, a user defin-
able temperature operating range, and “SetBack” & “Auto-Off”
functions to preserve tip life. To protect your more expensive
tip-heater cartridge and fine point soldering tips from oxidation,
the TD-100 can be used with the optional “Tip & Tool Stand with
Instant-Setback”. The Tip & Tool Stand puts the iron’s channel into
setback if it is idle in the Tip & Tool Stand for more than 45 seconds!
One Tip & Tool Stand with Instant-Setback can be connected to
the MBT 301.
The new dual purpose vacuum/pressure pump and delivery system
featuring PACE’s patented SNAP-VAC Technology, provides the
most vacuum available for desoldering applications. When used
with an air pencil, the high resolution, pressure control valve allows
for precise adjustment when working on the smallest components
such as 0201’s.

Specifications MBT 301 MBT 350 MBT 301 E MBT 350 E

Kit with Handpieces Part Numbers: 8007-0478 8007-0454 8007-0479 8007-0455
(TD-100 & SX-100) (TD-100, MT-100 & SX-100) (TD-100 & SX-100) (TD-100, MT-100 & SX-100)
Power Source Only Part Numbers: 8007-0480 8007-0452 8007-0481 8007-0453
Power Requirements 120 VAC, 60 Hz (240 watts maximum) 230 VAC, 50 Hz (240 watts maximum)
®
IntelliHeat Compatibilty IntelliHeat Handpieces with Tip Heater Cartridge or SensaTemp Technology
®
®
Dimensions 135mm (5.3") H x 165mm (6.5") W x 260mm (9.25") D
Weight 5 Kgs (11 lbs.)
Tip to Ground Resistance < 2 Ohms
Temperature Stabililty ± 1.1°C (2°F)
Temperature Accuracy Meets or exceeds ANSI J Std 001
37-482°C (100-900°F) SensaTemp ®
Set Temp Range
205-454°C (400-850°F) tip Heater Cartridge
Vacuum Rise Time 150 ms Average

Vacuum 20 in Hg max
Pressure 18 p.s.i. max
Air Flow 8 SLPM max
