Ersa IRHP 200 infrared heating plate
     Accessories and process materials

            The Ersa IRHP 200 is a compact and ergonomically designed
            heating plate to preheat all SMD components as well as as-
            semblies and substrates during the hand soldering process.
            It can also be used to reflow solder one-sided SMD boards
            and for reballing BGAs.
            The IR emitters´ even heat distribution ensures non-contact,
            gentle heating of the assembly. Thus the IRHP 200 is per-
            fectly suited for lead-free applications.
            The control station can be placed independently from the
            heating plate on the workbench in an ergonomically favor-
            able way.






                                                                                    Ersa IRHP 200
                                                                                    Electronically temperature-controlled
                                                                                    infrared rework heating plate with in-
                                                                                    tegrated thermocouple, incl. control
                                                                                    station 0RA4500D


                                                       Application example with optionally
                                                       available X/Y PCB table 0IR5500-01


            Order no.  Description                       Heated area   Dimensions     Rating/      Weight
                                                         (L x W)       (L x W x H)    voltage
            0IRHP200   IRHP 200 infrared rework heating plate with   260 x 135 mm  300 x 250 x 90 mm  max. 800 W /   approx. 4 kg
                       control station 0RA4500D                                       230 V~, 50 – 60 Hz


            Ersa IRHP 100 A infrared heating plate


            The IRHP 100 A infrared heating plate offers bottom-side
            PCB preheating for hand soldering, desoldering and touch-
            up applications. The safe and powerful medium wavelength
            IR heating technology offers a tremendous benefit to today’s
            workbench. Working temperatures of the soldering tools can
            be greatly reduced. Lower tip temperatures decrease the risk            Ersa IRHP 100 A
            of PCB damage while at the same time greatly increasing tip             Infrared rework heating plate, con-
            lifetime. The heating plate is controlled by either the                 trolled in 6 stages via the optional
            i-CON 1C or the i-CON 2C.
                                                                                    i-CON 1C control station
            Order no.  Description                       Heated area   Dimensions     Rating/      Weight
                                                         (L x W)       (L x W x H)    voltage
            0IRHP100A-03  IRHP 100 A infrared rework heating plate  125 x 125 mm  200 x 260 x 53,5 mm  250 W (stage 6)   approx. 2.6 kg
                                                                                      230 V~, 50 – 60 Hz
            0IRHP100A-04                                                              115 V~, 50 – 60 Hz

            Ersa special tools


            The Ersa 185 PZ plastics welding device can be used to
            cut, weld and seal thermoplastic foil, fabric and sealing sec-
            tions. In cutting plastic cords, the Ersa 185 PZ simultaneous-
            ly welds the ends, to prevent untwisting.
                                                                            50
                                                                                    Ersa 185 PZ
                                                               100
                                                                                    Plastics welding device


            Order no.  Description                     Rating/        Heating time   Temperature  Weight
                                                       voltage                       range        (w/o cable)
            0185PZ   Ersa 185 PZ plastics welding device with   150 W/230 V  approx. 5 min  approx. 370 °C  370 g
                     welding blade 0182PZ004
            1185PZA068                                 150 W/115 V
