Ersa stacking rack STR 100 and STR 200
Accessories and process materials

The Ersa STR 100 stacking rack can be used for combining
two soldering stations, e.g. the DIG 2000 A electronic station
with the vacuum unit as required (see adjacent illustration)
in a practical and space-saving way.
The Ersa STR 200 stacking rack can be used for combining
two i-CON soldering stations or one i-CON station with any
other Ersa soldering station.

STR 100/STR 200
Stacking racks for a well-organized workplace
(delivery without soldering stations)

Order no. Description

0STR100 STR 100 stacking rack to arrange soldering stations (except i-CON) in a safe and space-saving way on the workbench
0STR200 STR 200 stacking rack to arrange the Ersa i-CON soldering stations in a safe and space-saving way on the workbench

Ersa SR 100 solder wire dispenser

The Ersa SR 100 solder wire dispenser is extremely durable
and can accept solder wire reels of up to 1,000 g.
Optimal unwinding of different reels is ensured by a conical
centering nut.
The flexibly mounted solder wire guide is suitable for all cur-
rent solder wire diameters and allows unwinding in the de-
sired direction without having to change the location of the
SR 100.
SR 100
Available as an accessory and easily retrofitted, the Ersa
SR 101 kit allows simultaneous use of a second spool. Solder wire dispenser (delivery without
solder wire)
SR 101
Retrofit kit for a second solder wire spool,
optionally available
(delivery without solder wire and SR 100)

Order no. Description Solder wire spools Spool receiver diameter
0SR100 SR 100 solder wire dispenser for one spool 250 g, 500 g, 1,000 g 14 mm
0SR101 Retrofit kit SR 101 for a 2nd spool 250 g, 500 g, 1,000 g 14 mm

Ersa tip exchanger

For changing all internally heated soldering and desoldering 3ZT00164
tips as well as hot-air nozzles, we recommend tip exchanger
3ZT00164 with flat nose pliers and side cutter. These special Tip exchanger with flat nose pliers and
side cutter
pliers allow tips to be replaced safely and protectively, even
when hot.

Order no. Description Application

3ZT00164 Tip exchanger For changing all internally heated Ersa soldering tips and desoldering tips
of the 422/452 desoldering tip series and 802 hot-air nozzles
32
