P. 246
Volume fume extraction | Exhaust hood
Exhaust hood
WEHT Exhaust hood for rising fumes
Extraction hood WEHT with Easy-
Click 60 exhaust top connector
Order No. FT91000022N
For applications where fumes spread rapidly due to a drafty
work environment.
The hood can enclose the source, enabling fumes to be
captured before they contaminate the workplace
The housing is PET and is NOT ESD safe
Comes with 700-3051-ESD extraction hose Easy-Click 60 (60
mm diameter), 3 meters long
Compatible with Weller Zero Smog 4V or Zero Smog 6V
systems
Accessories Order No. Model Description
700-3051-ESD Extraction hose Easy-Click 60 Extraction hose Ø 60 mm, length: 3 meter
3 meter
FT910 04 699 Zero Smog 2 Fume extraction unit Zero Smog 2
WEHB Exhaust hood for glueing / cleaning
WEHB Extraction Hood Bottom for
gluing or cleaning applications
Order No. FT91000023N
Bottom source extraction hood for gluing or cleaning
applications where gases from solvents or glue, lighter than air
have to be extracted from below
Mobil use on a bench or trolly
To guarantee sufficient extraction results an extraction unit with
minimum 230 m3/h must be connected to the hood
The workplace is covered with a punched stainless steel plate
Comes with the 700-3051-ESD extraction hose Easy-Click 60
(60 mm diameter), 3 meters in length
Accessories Order No. Model Description
700-3051-ESD Extraction hose Easy-Click 60 Extraction hose Ø 60 mm, length: 3 meter
3 meter
FT910 05 699 N Zero Smog 2 Fume Fume extraction unit Zero Smog 2
extraction unit for
Adhesive fumes
246 Filtration
