Volume fume extraction | Easy-Click 60 Extraction Arms

Easy-Click 60 Extraction Arms
Volume extraction

The Weller Easy Click 60 system is a flexible, easy-
to-install connector system for quickly and safely
putting together surface extraction systems as you
want—without any tools*.
The ESD-safe Easy Click 60 modules provide a variety of
connection solutions and are suitable for every application at
the workstation. The individual elements can be combined with
each other or expanded for individual requirements based on
the modular principle.
In addition, thanks to the logical design, the elements can be Tip Extraction
quickly and flexibly adapted to modified production conditions.
*Except in the case of air intake ports

Kit 1 WF 32

Easy-Click 60 extraction arm with sloped
nozzle, length 1 m, Ø 32 mm, stop valve.
Laser Extraction

Order No. T005 87 627 70N
Scope of supply Order No. Model Description
700-3051-ESD Extraction hose Easy-Click 60 Extraction hose Ø 60 mm, length: 3 meter
3 meter
T005 36 574 99N Easy-Click 60 Stop Easy-Click 60 Stop valve for table connection of and flex arm and
valve extraction hose including air flow valve and 2 bench mounting
brackets.
T005 36 580 99 WF 32 Extraction WF 32 ESD microscope extraction arm
Arm 32 mm, with Accessories Volume extraction
sloped nozzle
T005 87 628 34 Sloped Nozzle Sloped aluminium nozzle for 32 mm flex arms, Ø 31 mm, length
31 mm 60 mm

Spare filter

Filtration 249
