Data analysis
With the portable instrument DryLogger and the so ware LogManager

supplied with every cabinet you can calculate the me intervals and
percentage that exceed the 10%RH or 5%RH which leads to the

estima on of the MSD floor life ( “Floor Life” is the allowable time

period after removal from a moisture barrier bag, dry storage or
dry bake and before the solder process reflow).
Another typical data analysis is the graph of the door opening.
40°C Baking
Some cabinets version can do 40°C low baking process of SMD
components.
At this temperature the reels are not damaged and can be a erwards

inserted into the feeders of the pick and place without problems.

ADDITIONAL SHELF AND WHEEL KIT ESD (OPTIONAL)

8106.840 Addi onal shelf 510x606x18 mm , Ghibli-PRO 700 and 350. 100Kg Max.
8106.841 Addi onal shelf 1094x606x18 , Ghibli-PRO 1400. 100Kg Max.
8106.850 Wheel Kit ESD

FAST RECOVERY MODULE (OPTIONAL)

The FAST RECOVERY 8106.820 module is an immediate ac on dehumidifier. By exploi ng the

physical characteris cs of compressed air (free of humidity) or nitrogen, it allows the humidity

inside the GHIBLI cabinets to be reduced in just a few seconds. Connected to the cabinet
hygrometer, it allows you to maintain the humidity level within the established limits.
8106.820 FAST RECOVERY module 8106.820
FAST RECOVERY
TEKDRY MODULE (INCLUDED)

The TekDry is a zeolite dehumidifier module (element that absorbs humidity), designed to work

con nuously, capable of lowering the humidity level up to 2%RH depending on the environment.

Opera ng ambient temperature: 5 °C < T < 35 °C

Opera ng ambient humidity 5% < RH <90%
Power supply: 200÷240 Vac 50/60Hz
Average power: 40W
Maximum power 250W

8104.852 Zeolite dehumidifier module

8104.852
TEKDRY
Tray rack (OPTIONAL)
Professional tray rack made of stainless steel that can be placed
on the trays of the Ghibli-PRO dry cabinets.
8106.866 GHIBLI-PRO - RACK 10 trays store
8106.583 Aluminium tray 495x570x12mm

ALARM BOX (OPTIONAL)
With this op on it's possible to set an alarm that become ac ve when, a er a certain period of me,

humidity or temperature are above a predetermined maximum threshold.
The Alarm Box has a warning light and a buzzer that can be silenced from a switch on the panel.
8104.856 Alarm Box for Ghibli-PRO cabinets
