Temperature Control Humidity Control
(Included both on Sahara and Sahara DRY models) (Included on Sahara DRY models only)

Temperature electronic control with PID regulator Humidity electronic control

and mul func on mer. Humidity control: <5% RH when 40°C ≤ T ≤ 100°C
Temperature Range: 40-280°C Humidity range: 1-95%RH
Accuracy: ± 1.5 °C Accuracy: ±2%RH

Resolu on: ± 1 °C Resolu on: ± 0.1 %RH

The digital controller has an internal clock with back-up that can keep It can work in 2 modes:
the right clock for a week without power supply. This is useful to mi- Fast: dehumidifi ca on occurs at the maximum possible speed.

nimize the damage caused by any black-out when the oven is working Eco: dehumidifi ca on is propor onal adjustment to op mize the con-

in "Countdown", "Programmed start-up" or "Thermal programmer" sump on of compressed air. This mode is for a more ra onal use of

mode. The Sahara ovens can work in 4 modes: compressed air, in fact, the low level of humidity is reached for subse-
1) SetPoint: quent cycles and not in a direct way.
The oven reaches a setpoint temperature and stays steady. The Sahara DRY Ovens must be fed with dry air from 3 to 8 atm.
2) Countdown: How much should be dry the air supply?

It's like the SetPoint mode but with a me limit. A er the countdown Normally, centralized systems of compressed air are already equipped

me is expired the oven stops.Time limit can be set from 1 minute to with dehumidifi ca on system good enough to work properly with this
999 hours and 59 minutes. humidity control.
3) Programmed start-up: For example, a compressed air system to 7 bar with a dew point of less

It's useful when you want to start-up the oven on a precise date/ me than 3°C is usually sufficient.

(for example at 6:30 on monday a er the weekend the oven start-up

to SetPoint 200°C) How much is the compressed air consump on?
4) Thermal programmer: The dry air is blown into the inner chamber very slowly and only
It's possible to edit on a PC and then download to the digital control- when necessary.
ler up to 10 programs with 100 steps each. In every step you can set: Max consump on: 100 nl per minute

the temperature setpoint, the maximum gradient to reach it and the Average consump on: 30 nl per minute

dura on.
To set the thermal programmer it is necessary to have the 8107.215 Can be used the nitrogen and what advantages there are?
op on, comprehensive of the PidManager so ware and the special USB Yes. The baking in inert environment reduces oxida on of the PCBs

cable (see next page) and SMD components..
Sahara MODEL Shelf Int. Dimensions Ext. Dimensions Power Weight
8107.103 Sahara 40 litre 1/7 348x312x367 686x515x575 800/230V 35
8107.105 Sahara 60 litre 2/7 408x372x422 746x570x605 1200/230V 40
8107.107 Sahara 80 litre 2/8 458x372x472 796x570x680 1200/230V 45
8107.109 Sahara 120 litre 2/9 498x477x512 836x680x720 1600/230V 50
8107.111 Sahara 250 litre 2/14 593x522x797 956x730x1025 3200/230V 90
8107.113 Sahara 400 litre (with wheels) 2/18 693x607x980 901x815x1487 3200/230V 140
8107.108 Sahara DRY 80 litre 2/8 458x372x472 796x570x680 1200/230V 45
8107.110 Sahara DRY120 litre 2/9 498x477x512 836x680x720 1600/230V 50
8107.112 Sahara DRY250 litre 2/14 593x522x797 956x730x1025 3200/230V 90
8107.1xxW (OPZIONE) Opzione porta con fi nestra per ispezione, 200x200mm
8107.1xxH (OPZIONE) Opzione foro laterale per passaggio cavi, Ø 50mm
ADDITIONAL SHELF (OPTIONS)
8107.150 Addi onal shelf for Sahara 40 litre. Max 7Kg. (max. 7 shelves)

8107.152 Addi onal shelf for Sahara 60 litre. Max 7Kg.. (max. 7 shelves)

8107.154 Addi onal shelf for Sahara and Sahara DRY 80 litre. Max 7Kg.. (max. 8 shelves)
8107.156 Addi onal shelf for Sahara and Sahara DRY 120 litre. Max 7Kg.. (max. 9 shelves)

8107.158 Addi onal shelf for Sahara and Sahara DRY 250 litre. Max 7Kg.. (max. 14 shelves)

8107.160 Addi onal shelf for Sahara 400 litre. Max 7Kg.. (max. 18 shelves)
81
