Test Station

Test sta on for checking personnel grounding connec on of wrist
straps and footwear, according to the IEC 61340-5-1.

Separate tes ng of le and right shoe; the test is executed at 50V

or 100V to provide more accuracy.
A relay output allows access to ESD Protected Area.
Internal ba ery supplied 9V or external 9Vdc. 9264.952

ISO9000 traceable Calibra on Report is included.

The personnel grounding test sta on can work in 4 modes:

1) Simultaneus measurement of wrist straps and footwears.
2) Wrist straps only measurement 9264.950
3) Footwears only measurement
4) HandsFree mode (if the serial measure of the two footwears
pass the test then the internal relay enables the gate to the
EPA area)

ERROR ( >High Limit )
OK ( In Limit )
ERROR ( <Low Limit )

LOW limit HIGH limit

Wrist strap 750KΩ 35MΩ

10MΩ – 35MΩ – 70MΩ – 100MΩ – 200MΩ
0 - 100KΩ
Footwear (selectable) or:
(selectable)
1GΩ for the Atex compliant version

9264.950* Personnel Grounding Test Station wall mounting including: Wristlab-II instrument,
footplate and yellow panel.

9264.952* Personnel Grounding Test Sta on on Stand-up support including: Wristlab-II instrument,
footplate, yellow panel and stand-up support
9264.960 Wristlab-II instrument

9264.950.1G* ATEX version for code 9264.950* (Footwear High Limit = 1GΩ)
9264.952.1G* 9264.952.1G* ATEX version for code 9264.952* (Footwear High Limit = 1GΩ)
9264.960.1G ATEX version for code 9264.960 (Footwear High Limit = 1GΩ)

9264.955 Instrument recalibra on (ISO9000 Traceable Calibra on Report is supplied)
* Aggiungere al codice: I (Italiano), F (Francese), E (Inglese), D (Tedesco), H (Ungherese), S (Spagnolo)

CONTINUOUS MONITOR

This instrument con nuously monitors the integrity of the operator and one ESD
worksurface. It uses the "wave distor on" technology to avoid false alarms caused by

voltage offset, 50Hz fields and other electro-magne c and electrosta c interference.

7
Screw Terminal to monitor the worksurface's path-to-ground (requaired R<10 Ω) with
cord included.
Wriststrap input: 10mm banana plug / 10mm snap adaptor
Supply: 24Vdc.
Dimensions: 98x53x23mm
9263.652 Con nuous Monitor with power 230/24Vac adapter included
