867/4 H TORX bits
®

Application: TORX socket screws H bits
®
Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders
4
Design: Extra-hard, ideal for less demanding screwdriving jobs e.g. in
wood
Extra-hard bits for semi-hard materials e.g. wood.
Torque increases continuously during screwdriving operations
– without any abrupt occurrence of peak loads – until the screw
Code mm mm head reaches the material surface. Extra-hard bits are made from
05135170001 TX 5 50 2" 3,0 10
a special material that extends the service life of the tool and redu-
05135171001 TX 5 70 2 / " 3,0 10
3
4 ces the danger of material breakage. Recognisable in the catalogue
05135172001 TX 6 50 2" 3,0 10
through the article letter H. The extra-hard bits can be identifi ed
05135180001 TX 6 70 2 / " 3,0 10 with their dark yellow colour.
3
4
05135173001 TX 7 50 2" 3,0 10
05135175001 TX 7 70 2 / " 3,0 10
3
4
05135174001 TX 8 50 2" 3,0 10
3
05135182001 TX 8 70 2 / " 3,0 10
4
05135177001 TX 9 50 2" 3,0 10
05135178001 TX 9 70 2 / " 3,0 10
3
4
05135176001 TX 10 50 2" 4,0 10
3
05135184001 TX 10 70 2 / " 4,0 10
4
05135185001 TX 15 50 2" 4,0 10
3
05135186001 TX 15 70 2 / " 4,0 10
4

Bits
867/4 KK TORX bits
®
TORX ball tip
®
®
Application: TORX socket screws
Drive: 1 / " hexagon, suitable for DIN 3126-F 6.3, ISO 1173 bit holders
4
Design: Ball end, tough-absorbing The spherical drive profi le means
that it is possible to swivel the axis
of the tool to that of the screw,
and therefore enable angled,
Code mm "around-the-corner" screwdriving
05059700001 TX 10 89 3 / " 5 jobs. This ball tip geometry – often
1
2
05059701001 TX 15 89 3 / " 5 found on L-keys – is now available
1
2
05059702001 TX 20 89 3 / " 5 on a number of Wera bits.
1
2
1
05059703001 TX 25 89 3 / " 5
2
05059704001 TX 30 89 3 / " 5
1
2
05059705001 TX 40 89 3 / " 5
1
2
