867/1 Z TORX W bits
®

Wera ABC

Application: TORX socket screws
®
Drive: 1 / " hexagon, suitable for DIN 3126-D 6.3, ISO 1173 bit holders TORX Wedge
®
4
®
Design: W = Wedge TORX , tough-absorbing, ideal for diffi cult The conical TORX profi le provides a
®
screwdriving jobs e.g. in sheet steel or metal better fi t in the screw. Combined with
a great recess depth this produces a
pinch eff ect.
Code mm
05066450001 TX 10 25 1" 10
05066455001 TX 15 25 1" 10
05066460001 TX 20 25 1" 10
05066465001 TX 25 25 1" 10
05066470001 TX 27 25 1" 10
05066475001 TX 30 25 1" 10
05066480001 TX 40 25 1" 10

867/1 ZA TORX bits with central pin
®

Wera ABC
Bits
Application: SPAX T-STAR plus screws
TORX with pin Drive: 1 / " hexagon, suitable for DIN 3126-D 6.3, ISO 1173 bit holders
®
4
The protruding pin that fi ts into the Design: Central pin, tough-absorbing, ideal for diffi cult screwdriving
borehole of the screw makes it easier jobs e.g. in sheet steel or metal
to centre the tool in the screw recess.

Code mm mm
05066080001 TX 10 25 1" 4,0 10
05066081001 TX 15 25 1" 4,0 10
05066082001 TX 20 25 1" 5,0 10
05066083001 TX 25 25 1" 5,0 10
05066084001 TX 30 25 1" 6,0 10
05066085001 TX 40 25 1" - 10
