¼"

867/1 H TORX bits 867/1 TZ TORX bits
®
®

Application: TORX socket screws
®
®
Drive: 1 / " hexagon, suitable for DIN 3126-D 6.3, ISO 1173 bit holders Application: TORX socket screws
4
Design: Extra-hard, ideal for less demanding screwdriving jobs e.g. in Drive: 1 / " hexagon, suitable for DIN 3126-D 6.3, ISO 1173 bit holders
4
wood Design: Torsion-style design to reduce premature wear,
tough-absorbing, ideal for diffi cult screwdriving jobs e.g. in
sheet steel or metal
Code mm mm
05135140001 TX 1 25 1" 1,5 10
05135141001 TX 2 25 1" 1,5 10
05135142001 TX 3 25 1" 2,0 10 Code mm mm
05066300001 TX 5 25 1" 4,2 10
05135143001 TX 4 25 1" 2,0 10
05066301001 TX 6 25 1" 4,2 10
05135150001 TX 5 25 1" 3,0 10
05135152001 TX 6 25 1" 3,0 10 05066302001 TX 7 25 1" 4,2 10
05135154001 TX 7 25 1" 3,0 10 05066303001 TX 8 25 1" 4,2 10
05066304001 TX 9 25 1" 4,2 10
05135156001 TX 8 25 1" 3,0 10
05066305001 TX 10 25 1" 4,2 10
05135158001 TX 9 25 1" 3,0 10
05066308001 TX 15 25 1" 4,2 10
05135160001 TX 10 25 1" 4,0 10
05135161001 TX 15 25 1" 4,0 10 05066310001 TX 20 25 1" 4,8 10
05066312001 TX 25 25 1" 5,5 10

05066313001 TX 27 25 1" 5,5 10
05066315001 TX 30 25 1" 6,0 10
867/1 KK TORX bits
®
05066320001 TX 40 25 1" - 10
Bits

Application: TORX socket screws
®
Drive: 1 / " hexagon, suitable for DIN 3126-D 6.3, ISO 1173 bit holders
4 ®
Design: Ball end, tough-absorbing TORX ball tip

Code mm The spherical drive profi le means
05066060001 TX 10 25 1" 10 that it is possible to swivel the axis
05066061001 TX 15 25 1" 10 of the tool to that of the screw,
05066062001 TX 20 25 1" 10 and therefore enable angled,
05066063001 TX 25 25 1" 10 "around-the-corner" screwdriving
05066064001 TX 30 25 1" 10 jobs. This ball tip geometry – often
05066065001 TX 40 25 1" 10 found on L-keys – is now available
on a number of Wera bits.
