Page 46 - EREM katalógus

Side Cutters and Tip Cutters

Series 2400 MagicSense

A = length of cutting edges
D B = head width
C = head thickness
D = head length

Tip cutter Tip cutter Tip cutter Side cutter Side cutter
Straight long relie- Angled narrow Angled wide Tapered head Oval head
ved head head head

Visibility and accessibility Robustness, high cutting capacity

Side cutter – oval head

130 mm/ 5.118 Inch This is the most widely used head shape.
70 g / 2.47 oz. It is robust and size for size offers the highest cutting capacity.

Model Cut Dimensions in mm/Inch Max. cutting capability in mm/Inch Diameter
A B C D Hard wire Medium hardness Copper wire
2412E 12 11 6 19 0.5 1.0 1.6
Semi-flush .472 .433 .236 .748 .019 .039 .062
2422E 12 11 6 19 – 1.0 1.6
Flush .472 .433 .236 .748 .039 .062
2432E 12 11 6 19 – 0.8 1.6
Super full flush .472 .433 .236 .748 .039 .062

Wire quality, see P. 38
Optional: Safety device for wire scraps. Order suffix "W“, e.g. 2412W.

Side Cutters and Tip Cutters 47
