Soldering Stations | WX Line

WX 2 Soldering station

A NEW ERA IN SOLDERING.

Cost saving because only one power unit is needed for different applications.
Use as benchtop controller saves energy.
Lowering the running costs by enlarged tip lifetimes.
Reduction of rework due to optimized tool use
and correct working temperature.

TECHNICAL DATA

Channels 2 Visual process control
Dimensions L x W x H (Inches) 6,85 x 6,06 x 5,31 through LED signal function
Dimensions L x W x H (mm) 174 x 154 x 135 Blue LED ring light (light is out = Off, light
Weight (approx.) in kg 3.45 is blinking = standby or heating up, light is
Voltage 230 V, 50 Hz on = tip ready for use)
Power 200 W (255 W) Tailor-made performance
Protection class I Weller heating technologies deliver precise
Fuse T2A performance on demand.
Temperature range 100 - 550
(depends on tool) °C
Temperature range 210 - 999 Quick heating time
(depends on tool) °F
Temperature accuracy °C ±9 WX soldering irons heat in ultra-quick time
and can be used immediately.
Temperature accuracy °F ±17
Temperature stability °C ±2
Temperature stability °F ±4 Temperature stability/accuracy
Equipotential bonding . All WX soldering tools have a temperature
1x USB, 2x RS232, 1x ± 2 °C
Interface stability of ± 2° C and a temperature
Switching output accuracy of ± 9° C, as per IPC standard.
ESD-safe .
Automatic tool identification .
Traceability (unit data) . Intuitive operation
255 x 128 dots /
Display The robust touch screen is a capacitive
Backlighting touch panel made of real glass. It is anti-
USB port . static and temperature-resistant. The turn-
Via 3,5 mm pawl socket and-click wheel with confirm button allows
Equipotential bonding socket
on back of device intuitive operation.
Benchtop controller .
Huge energy savings
Motion sensor
Thanks to an integrated sensor, WX tools
are motion activated. This means that
they consume power only when they are
actually in use. Connected accessories
also go into standby mode.

40 Soldering Equipment
