Soldering Stations | WX Line

WXD 2 Desoldering station Soldering Stations

REMOVE SOLDER WITH THE

FASTEST DESOLDERING Soldering iron

IRONS IN THE WORLD. and safety rest

Soldering tips and nozzles

TECHNICAL DATA External compressed air supply
The maintenance-free Venturi unit Preheating plates
Channels 2 produces a constant vacuum using an
external compressed air supply.
Dimensions L x W x H (Inches) 6.69 x 5.94 x 5.12
Dimensions L x W x H (mm) 174 x 154 x 135
Weight (approx.) in kg 3.8 Fastest desoldering iron
Voltage 230 V, 50 Hz With its 120 watts and extremely short
Power 200 W (255 W) heating time, the desoldering iron can Soldering bathes
Protection class I easily handle jobs that would have been
Fuse T2 A difficult in the past, including desoldering
high mass PCBs.
Temperature range 50 - 550
(depends on tool) °C No tedious cleaning
Temperature range 150 - 999 The new, extended nozzle shaft prevents the
(depends on tool) °F suction tube from sticking. Since the suction Circuit board holder
Temperature accuracy °C ±9 channel has also been replaced, the once
tedious and time-consuming task of cleaning
Temperature accuracy °F ±17 the tool is now a thing of the past.
Temperature stability °C ±2
Temperature stability °F ±4 Quick replacement
Thanks to ingenious mountings, the
Equipotential bonding . suction nozzle and solder cartridge can be Solder feeder
1x USB, 2x RS232, 1x changed quickly and easily – without the
Interface
Switching output risk of burns or tricky replacement work.
ESD-safe .
Huge cost savings
Automatic tool identification . The relatively low operating temperature
(380°C) and automatic standby mode
Traceability (unit data) . controlled by the use sensor increase the
Air consumption l/min 35 service life of the suction nozzles by a Hot air heating gun
Built-in pump factor of 3.
Vacuum max. 55 kPa (8psi) Vacuum run-on
IPC-compliant yes A vacuum run-on time can be set to
Outer diameter 6 mm prevent the suction pump blocking.
Compressed air connection (0.24 "), oil-free, dry
compressed air Temperature measuring
USB port .
Benchtop controller . Two models are available.
255 x 128 pixels The WXDP 120 is designed for horizontal
Display operation and the WXDV 120 for vertical
/ Backlighting
Accessories
operation.

Soldering Equipment 35
