Page 165 - weller

Soldering tips and nozzles | Soldering tips

Round
A = Width mm
B = Thickness mm Soldering Stations
C = Length mm
Model A B C PU Order No. Model A B C PU Order No.
XNT 1LX 0.2 42.8 1 T005 44 872 99 XNT 1X 0.4 28 1 T005 44 865 99
Soldering iron and safety rest

XNT 1S 0.2 28.5 1 T005 44 852 99 XNT 1HS 0.5 27.2 1 T005 44 888 99
Soldering tips and nozzles

XNT CS 3.2 0.8 37.5 1 T005 44 870 99
XNT 1SLX 45° 0.4 39.5 1 T005 44 875 99

Preheating plates

Bevel Cut (Sloped)

A = Width mm
B = Thickness mm
C = Length mm Soldering bathes

Model A B C PU Order No. Model A B C PU Order No.
XNT 4 1.2 29.5 1 T005 44 855 99 XNT CC 45° 3.2 28 1 T005 44 886 99
Circuit board holder

XNT AA 45° 1.6 28 1 T005 44 884 99 XNT F 45° 1.2 28 1 T005 44 887 99

Solder feeder

XNT BB 45° 2.4 28 1 T005 44 885 99

Hot air heating gun

Temperature measuring

Accessories

Soldering Equipment 165
