Steel shelf
Module Size W x D mm Max load kg Code
M500 490 x 300 50 860 804-49
M500 490 x 400 50 860 805-49
M750 740 x 300 50 836 028-49
M750 740 x 400 50 852 770-49
M900 890 x 300 50 852 283-49 Steel shelf M500, M750, M900, M1000, M1350
M900 890 x 400 50 852 769-49
M1000 990 x 300 50 890 631-49
M1000 990 x 400 50 890 632-49
M1350 1340 x 300 50 860 787-49
M1350 1340 x 400 50 860 788-49
Due to the dual-purpose shelf brackets, the shelf can be used either as tilted
20° or in a horizontal position. The shelf has an integrated edge, which can
used either in the front or back of the shelf, depending of the use of the shelf.

Adjustable shelf Adjustable shelf, stepless depth adjustment
Module Size W x D mm Max load kg Code Module Size W x D mm Max load kg Code
M500 470 x 505 100 920 49 001P M500 470 x 505 50 920 49 003P
M500 470 x 650 100 920 49 002P M500 470 x 650 50 920 49 004P
M750 720 x 505 100 920 49 005P M750 720 x 505 50 920 49 007P
M750 720 x 650 100 920 49 006P M750 720 x 650 50 920 49 008P
M900 870 x 505 100 920 49 009P M900 870 x 505 50 920 49 011P
M900 870 x 650 100 920 49 010P M900 870 x 650 50 920 49 012P
M1350 1320 x 505 100 920 49 013P Also available as non ESD-versions (code 41 instead of 49).
M1350 1320 x 650 100 920 49 014P
Also available as non ESD-versions (code 41 instead of 49).

! Additional adjustable shelves on page 86.

Adjustable shelf, tilting Steplessly adjustable shelf,
0-25° tilting 0-25°

Extendable shelf
Module Size W x D mm Max load kg Code
M750 720 x 390 30 925 49 002P
M900 870 x 390 30 925 49 003P

Document shelf
Module Size W x D mm Max load kg Code Extendable shelf, tilting Document shelf, tilting 10 - 75°
M500 470 x 265 5 860 806-49 0-25°
M750 720 x 265 5 860 115-49
M900 870 x 265 5 860 399-49

Flow-through shelf
Module Size W x D mm Max load kg Code WORKBENCH ACCESSORIES Concept, LMT, TP
M750 718 x 830 150 890 710-49
A flow-through shelf can fit two 400-mm deep shelf bins successively. Flow-through shelf

Divider pair
Suitable for Size D x H mm Code
Steel shelf depth 300 mm 285 x 190 010 004-49
Steel shelf depth 400 mm 385 x 190 010 005-49
Tiltable top shelf TTS depth 300 mm 285 x 190 861 116-49 Divider pair

Treston - Ergonomic workspaces 45
