Accessories for Concept, LMT and TP

Upright tubes are the basic element for accessorising

Straight bracket Corner bracket our industrial furnishings. Accessories are attached to
Concept, LMT and TP benches with the aid of upright
Horizontal tube
tubes or a complete, upright tube module.
The complete upright tube module includes upright tubes,
corner bracket pair and straight bracket pair (if module
includes more than one horizontal tube). For the Concept
bench, the upright tubes are attached to the rear case of
Upright tube
h= the bench. With the TP bench, you also need an acces-
sory frame TPK (page 34). For the LMT bench, the LMT
l=
upright tube module is attached to the side of the bench.

Upright tubes for Concept and TP
Name Size W x D mm Length mm Code
Upright tube 30 x 60 500 860 991-49
Upright tube 30 x 60 800 860 142-49
Upright tube 30 x 60 996 860 367-49
Upright tube 30 x 60 1359 860 024-49
Upright tube 30 x 60 1582 860 025-49
Horizontal tube M500 860 819-49
Horizontal tube M750 847 402-49
Horizontal tube M900 840 104-49
Horizontal tube M1000 854 656-49
Horizontal tube M1200 854 655-49
Horizontal tube M1350 850 914-49
Horizontal tube M1500 854 654-49
! The modular (M) size Horizontal tube M1800 854 657-49
Corner bracket pair
848 336-49
The modular (M) size refers to the distance between two
upright tubes from the middle of the tube. The modular size Straight bracket 851 827-49
is used to find the appropriate accessories.
Upright tube modules for Concept and TP
Aluminium bracket
Suitable for bench widths Code Code
WORKBENCH ACCESSORIES Concept, LMT, TP
Name Code C = Concept l =1359 mm l =1582 mm
Aluminium bracket 846 554-00 1000 1200 1500 1800 2000 h =1075 mm h =1300 mm
1 x M750 C C/TP C C C 900 49 001P 900 49 002P
A separate aluminium bracket 1 x M900 C/TP C/TP C C C 901 49 001P 901 49 002P
can be used to attach a single 2 x M500 C C 902 49 001P 902 49 002P
tube to any bench. 2 x M750 C/TP C C 903 49 001P 903 49 002P
2 x M900 C/TP C 904 49 001P 904 49 002P
3 x M500 C C C 905 49 001P 905 49 002P
4 x M500 C 906 49 001P 906 49 002P
CC cable clip set CC5 h = module's height measured from Concept bench's top surface.
Name Suitable for Code ESD Upright tube modules are available also with 996 mm uprights (h=714 mm).
Cable clip set (5 pcs) Upright tubes CC5 Item codes: 90x49003P.
For easy cable management, suitable for up to five cables. Load capacity 100 kg / module spacing.
Upright tube modules include 5 pcs of cable clips for easy cable manage-
ment.

Upright tube modules for LMT
Module Height, mm Code
M1000 996 854 926-49
M1200 996 854 925-49
M1500 996 854 924-49
M1800 996 854 928-49
