CONCENTRIC RING PROBE

• Use for testing surface resistance to
EN 61340-5-1 and ESD S11.11
• Available with carbon loaded conductive pads
• Probe resistance with carbon
loaded pads: <500 ohms
• Made in Britain 222003
Part No. Description
222003 Probe Kit with Cable and Carry Case
222002 Concentric Ring Probe
Download Technical Bulletin TB-7549 Test Equipment

CYLINDER PROBES

• Used to measure point to point resistance (Rp-p),
resistance to ground (RG) and volume resistance
(RV) in accordance with EN 61340-5
• Carbon loaded conductive rubber pads that
do not mark the surface to be tested
• Internal resistance <50 ohms
• Made in Britain
Part No. Description
222008 63mm, 2.3kg, Black Probe 222009
222009 Boxed Set with Two 222008
Download Technical Bulletin TB-7550

TIP!
Where there is a field, there is also a charge!
Use a field meter to determine and demonstrate
the presence of electrostatic charges.

ESD SURVEY KIT
• Everything needed to conduct an ESD control program survey
• Kit includes all the tools required to survey to fulfill
your EN 61340-5-1 Compliance Verification Plan
• Contents:
(1) 50598 Ionisation Test Kit
(includes Digital Static Field Meter)
(1) 50553 HBM Test Fixture
(1) 222630 Surface Resistance Test Kit
(1) 222632 Resistance Meter Attachment
(1) 224713 Outlet Analyser 222685
(1) Fluke 114-A Meter
(1) 229904 Jewel Wrist Strap
(1) 249250 Foot Grounder
(1 set) Training Paddles
(1) Heavy duty carrying case
• Made in America
Part No. Description
222685 ESD Survey Kit
Download Technical Bulletin TB-6568
