Side Cutters and Tip Cutters
Special applications
A = length of cutting edges
D B = head width
C = head thickness
D = head length
Special applications – Special tool steel, ESD-safe
120 mm/ 4.724 Inch Side cutter with compound action.
100 g / 3.53 oz.
Model Cut Dimensions in mm/Inch Max. cutting capability in mm/Inch Diameter
A B C Copper wire
147A 12 10.5 7.5 1.8 For cutting hard wires with minimal effort
Semi-flush .472 .413 .295 .070
147AT 12 10.5 7.5 1.8 Model same as 147A, but with cutting edges made
Semi-flush .472 .413 .295 .070 from tungsten carbide, model on request
115 mm/ 4.527 Inch Side cutter, suitable for cutting printed-circuit boards.
79 g / 2.79 oz.
Model Cut Max. cutting capability in mm/Inch
Max. D Max. B
884EPCM* 1.5 2.0
Flush .059 .078
*Not available in North America
