Ersa high-speed soldering irons
Soldering irons and sets The Ersa MULTI-SPRINT is an extremely light, transformer- MULTI-SPRINT soldering PTC
range of
tips!
independent solder gun with a heat-up rating of up to 150 W
and an ergonomic design.
In combination with the internally heated ERSADUR longlife
Soldering tip series 832/842,
soldering tip, the MULTI-SPRINT’s PTC heating element of-
see page 40
fers especially high performance. The short heat-up time
makes it ideal for high-speed series soldering. The MULTI-
SPRINT is heated only as long as the button is pressed.
The large selection of tips of the 832 / 842 series affords a
wide range of applications, and not just in service and repairs.

Order no. Description With Rating/ Heating time Max. tip Weight
soldering tip voltage temperature (w/o cable)
0960ED MULTI-SPRINT solder gun 0832EDLF, 150/75 W/ approx. 15 s subject to how 100 g
ERSADUR 230 V, 50 – 60 Hz long the button
is pressed
1960EDA068 150/75 W/115 V, 50 – 60 Hz
Ersa power soldering iron with temperature control PTC

The Ersa PTC 70 is a powerful and sturdy universal soldering Wide
RESIS-
iron with Ersa RESISTRONIC temperature control. This proven TRONIC range of
temperature control system together with the ceramic PTC control soldering
heating element provides unusually fast heat-up and heat tips!
recovery.
Due to the accurate temperature control and the wide range
of ERSADUR longlife tips of the 832 and 842 series, the PTC 70
PTC 70 is a perfect tool for both very small solder joints as
well as for applications with medium heat requirements. The Soldering tip series 832/842, see page 40
PTC 70 is supplied with the soldering tip 0832CDLF.

Order no. Description With Rating/ Heat-up rating/ Temperature Weight
soldering tip voltage heating time range (w/o cable)
0710CD PTC 70 soldering iron 0832CDLF, 75 W (350 °C)/ up to 285 W/ 250 – 450 °C approx. 60 g
ERSADUR 230 V AC approx. 34 s (280 °C)
1710CDA068 75 W (350 °C)/115 V AC
Ersa power soldering iron with temperature control PTC

The Ersa MULTI-TC is a powerful, sturdy, temperature-con-
trolled universal soldering iron with a precise temperature
sensor located directly under the internally heated solder-
ing tip. This temperature sensor registers the actual tem-
perature in the immediate vicinity of the solder joint. The
heating system with internal PTC heating element immedi-
ately reacts to the heat loss and reheats extremely fast. MULTI-TC Wide
The high heating efficiency and the large selection of Soldering tip series 832/842, see page 40 SENSO- range of
TRONIC
soldering tips and inserts serve both filigree applications in control soldering
electronics and applications with standard soldering irons tips!
with a rating of up to 150 W. Examples are classical lead
glazing and Tiffany soldering.
By dispensing with a heavy transformer and thanks to its
heat-resistant connecting cable, the Ersa MULTI-TC is es-
pecially suitable for mobile use in service, maintenance and
repairs.

Order no. Description With Rating/ Heating time Temperature Weight
soldering tip voltage (to 280 °C) range (w/o cable)
0760CD MULTI-TC soldering iron 0842CD, 75 W (350 °C) approx. 34 s 250 – 450 °C 60 g
ERSADUR 230 V, 50 – 60 Hz

8
