Ersa miniature soldering irons
Soldering irons and sets The MINOR S (5 W) and MINI-TIP S (6 W) miniature sol- MINOR S MINI-TIP S

dering irons with ERSADUR tips are suitable for the finest-
detailed soldering work on micro-circuits.
The MINOR S can be operated with a 6 V transformer or a
6 V battery. Besides electronics, the MINOR S is also used
in watch repair, in the photographic industry and in dental
technology.
Soldering tip 012, see page 45
The MINI-TIP S can be operated with a 12 V battery.

With
Order no. Description Soldering tip series 042, see page 45 Heating time Max. tip Weight
Rating/
soldering tip voltage temperature (w/o cable)
0045BDG MINOR S soldering iron 0042BD, ERSADUR 5 W/6 V 12 s approx. 440 °C 6 g
0015BDH MINI-TIP S soldering iron 0012BD, ERSADUR 6 W/12 V 20 s approx. 390 °C 7 g

Ersa micro/universal soldering irons PTC

The Ersa MULTI-TIP series covers a wide range of applica-
tions. It stands out by its low weight and compact design
(short distance between soldering tip and the handle’s front MULTI-TIP C15
part). The handle stays relatively cool while soldering.
Soldering tip series 162, see page 44
The MULTI-TIP is available for 15 W and 25 W and suitable
for both micro-soldering joints and medium-sized soldering,
as on distributor strips. Longlife and industrially tested PTC
heating elements and internally heated soldering tips provide
high efficiency and fast heat supply. MULTI-TIP C25
Soldering tip series 172, see page 44
The TIP 260 is also heated in this especially efficient way.
16 W power and slim design make this soldering iron an ideal
aid when working on electronic assemblies in places difficult TIP 260
to access.
Soldering tip series 162, see page 44

Order no. Description With Rating/ Heating time Max. tip Weight
soldering tip voltage temperature (w/o cable)
0910BD MULTI-TIP C15 soldering iron 0162BD, ERSADUR 15 W/230 V approx. 120 s approx. 350 °C 28 g

0920BD MULTI-TIP C25 soldering iron 0172BD, ERSADUR 25 W/230 V approx. 90 s approx. 450 °C 34 g
0260BD TIP 260 soldering iron 0162BD, ERSADUR 16 W/230 V approx. 120 s approx. 350 °C 40 g

Wide
Ersa universal soldering irons range of
soldering
tips!
Thanks to its large range of tips, the Ersa MULTI-PRO is the
ideal soldering iron when great flexibility is required. It has a
heat-resistant connecting cable. Internally heated tips pro- MULTI-PRO
vide a high level of efficiency.
Soldering tip series 832/842, see page 40
Ersa 30 S, the best selling and most tried and tested uni- 30 W 40 W
versal soldering iron, is known the world over for its sturdi-
ness and longevity. It can be used in a variety of ways for
soldering tasks in handicrafts, service and hobbies. Delivery
includes a practical, easy to mount rubber stick-on support *
disk. The Ersa 30 S is available with 30 W and 40 W. Ersa 30 S
Soldering tip series 032, see page 45
* Also available with heat-resistant cable, order no. 0330KD0028.

Order no. Description With Rating/ Heating time Max. tip Weight
soldering tip voltage temperature (w/o cable)
0930CD MULTI-PRO soldering iron 0832CDLF, ERSADUR 20 W/230 V approx. 5 min approx. 430 °C 60 g
0330 KD Ersa 30 S soldering iron 0032KD, ERSADUR 30 W/230 V approx. 2 min approx. 380 °C 80 g
1330KDA068 30 W/115 V
0340 KD Ersa 30 S soldering iron 0032KD, ERSADUR 40 W/230 V approx. 2 min approx. 420 °C 80 g
