Ersa RDS 80 soldering station PTC

The Ersa RDS 80 digital soldering station offers the Ersa
RESISTRONIC temperature control, tried and proven for many
years and now with 80 W heating power. Soldering stations
The ceramic PTC heating element (positive temperature
coefficient) acts as the temperature sensor in this control Super
system and ensures extremely fast heating thanks to the price-per-
high initial output. formance
ratio
High heating power and the large selection of soldering tips
allow a very wide range of applications. The heating system
with the internally heated soldering tips has a high thermal
efficiency.
The redesigned ergonomic handle, the housing design and
the large, digital multifunctional display do not leave much to
be desired.
RDS 80
Besides the arbitrary temperature selection between with RT 80 soldering iron, Ersa RESISTRONIC control system
150 °C and 450 °C, three fixed temperatures or two fixed Soldering tip series 832 and 842, see page 40
temperatures and one standby temperature can be
programmed. RT 80: very slim soldering iron featuring a large selection of soldering tips
In addition to a power bar graph display the station also
has a calibrating and power-off feature. The potential
equalization socket (with an integrated 220 kΩ resistor)
allows the soldering tip to be equalized with the workplace
potential.
The RT 80 soldering iron has a sprayed-on, flexible PVC
connecting cable.
Potential equalization Application example Multifunctional display
For tip exchange we recommend to use the tip exchanger socket
3ZT00164 (see page 32).

Ersa ANALOG 60/60 A soldering stations PTC

The electronically temperature-controlled ANALOG 60 The ANALOG 60 A soldering station is
soldering station is the basic model of the Ersa soldering especially suitable for producing small
station series. It has the tried and proven Ersa RESISTRONIC and medium-sized solder joints.
temperature control technology, with the ceramic PTC For tip exchange we recommend to
heating element serving as the temperature sensor. The high use the tip exchanger 3ZT00164 with
initial power enables fast heat-up.
an additional flat nose pliers and side
The large selection of soldering tips allows a broad range cutter (see page 32).
of applications. The internal heating provides high thermal Application example
efficiency. A front-installed socket with integrated, high-
impedance allows potential equalization between the
soldering tip and the workplace.
The device is primarily used for smaller and medium-sized
solder joints. The low-voltage operated soldering iron
BASIC TOOL 60 has a highly flexible, heat-resistant
connecting cable.
The electronically temperature-controlled Ersa ANALOG 60 A
soldering station is antistatic according to the MIL-SPEC / ANALOG 60 ANALOG 60 A
ESA standard and has all the positive features of the Ersa with BASIC TOOL 60 soldering iron, Ersa with ERGO TOOL soldering iron, Ersa
ANALOG 60. RESISTRONIC control system RESISTRONIC control system
The light and slim ERGO TOOL soldering iron has a highly Soldering tip series 832 and 842, Soldering tip series 832 and
flexible, heat-resistant and antistatic connecting cable. see page 40 842, see page 40

Order no. Description Rating/voltage Heating time Temperature Weight
range (with cable)
0RDS80 RDS 80 soldering station, complete, 80 W/230 V, 50 – 60 Hz/24 V 150 – 450 °C
with RT 80 soldering iron 0890CDJ, 105 W (280 °C) approx. 40 s approx. 130 g
1RDS800000A67 soldering tip 0842CD and tool holder 0A39 80 W/115 V, 50 – 60 Hz/24 V, 105 W (280 °C) (280 °C)
0ANA60 ANALOG 60 soldering station, complete, with 60 W/230 V, 50 – 60 Hz/24 V 150 – 450 °C
BASIC TOOL 60 soldering iron 0670CDJ, with 60 W (350 °C) approx. 60 s 60 g
soldering tip 0832CDLF and tool holder 0A42 (280 °C)
0ANA60A ANALOG 60 A soldering station, complete, 60 W/230 V, 50 – 60 Hz/24 V 150 – 450 °C
with ERGO TOOL soldering iron 0680CDJ, with 60 W (350 °C) approx. 60 s 60 g
soldering tip 0832CDLF and tool holder 0A42 (280 °C)
