Side Cutters and Tip Cutters | Series 600 Micro

Side cutter – pointed relieved head

Ÿ This is the narrowest head shape.
Ÿ The underside is relieved and
facilitates optimum access even to Side cutters and tip cutters
4.331 Inch / 110 mm extremely hard-to-reach areas.
1.69 oz. / 48 g

Model Cut A B C D Max. cutting capability in mm
Inch mm Inch mm Inch mm Inch mm Hard wire Medium Cop-
hardness per
wire
622NB 0.354 9 0.39 9.8 0.236 6 0.65 16 - Ø 0,6 Ø 0,8 Pliers
Flush
676E 0.354 9 0.354 9 0.236 6 0.590 15 - Ø 0,6 Ø 0,8
Flush
776E 0.354 9 0.354 9 0.236 6 0.590 15 - Ø 0,6 Ø 0,8
Perfectly flush cut
632NCF 0.354 9 0.354 9 0.236 6 0.590 15 suitable for precision cuts on soft
Perfectly flush cut materials, e.g. small silicone tubes,
precision connector seals, miniature
rubber seals, soft synthetic parts

Tweezers
Tip cutter - straight short relieved head

Ÿ Suitable for cutting SMD and
micro-package contacts.

4.331 Inch / 110 mm
1.69 oz. / 48 g

Special tools

Model Cut A B C D Max. cutting capability in mm
Inch mm Inch mm Inch mm Inch mm Hard wire Medium Copper
hardness wire
670E 0.118 3 0.354 9 0.236 6 0.709 18 - Ø 0,5 Ø 0,8
Flush
670EP 0.118 3 0.354 9 0.236 6 0.709 18 Ø 0,5 Ø 0,6
Flush
670EPF 0.118 3 0.354 9 0.236 6 0.709 18 - Ø 0,4 Ø 0,6
Flush
Kits

Precision Tools 317
