Soldering tips and nozzles | Hot air nozzles

Hot air nozzles for HAP 3000 (WHA 3000P / V), HAP 2

(WHA 2000) and HAP 3 (WHA 700, WHA 300) Soldering Stations

Round nozzle

Soldering iron and safety rest
Model Description Diameter PU Order No.
NR04 Round nozzle, without vaccum 2,5 mm 1 T005 87 368 81N

NR05 Round nozzle, without vacuum 4,0 mm 1 T005 87 368 67N
Soldering tips and nozzles

NR10 Round nozzle, without vacuum 7,0 mm 1 T005 87 368 70N

Preheating plates
NRV07 Hot air nozzle with vacuum for small components 7,0 mm 1 T005 87 507 70N

NRV10 Hot air nozzle with vaccum for small components 10,0 mm 1 T005 87 507 72N
Soldering bathes

NRV12 Hot air nozzle with vacuum for small components 12,0 mm 1 T005 87 507 74N

NR02 Round nozzle, without vacuum 1,7 mm x 1 T005 87 368 82N
45° Circuit board holder

NR06 Round nozzle, without vacuum 6,0 mm x 1 T005 87 507 65N
45°

Solder feeder
DR05 Dual nozzle round, without vacuum 2 x 2,5 1 T005 87 368 83N

2 sides heated (type ND, Width X = heated side)

Model Description Length Width PU Order No.
mm mm Hot air heating gun
ND05 Hot air nozzle, 2 sides heated 10.7 10.7 1 T005 87 368 43N

ND10 Hot air nozzle, 2 sides heated 14 10.0 1 T005 87 368 42N
Temperature measuring

ND15 Hot air nozzle, 2 sides heated 19 12.0 1 T005 87 368 41N

Accessories
ND20 Hot air nozzle, 2 sides heated 21.5 14.8 1 T005 87 368 40N

Soldering Equipment 183
