CHARIOTTE descrip on ref. Qnt.
Smd reel holder 8100.050 Stainless steel baseplate with castors, 600x760(L2) mm x
8100.049 Stainless steel baseplate with castors, 600x1130(L2) mm Z 1
8100.054 Stainless steel lateral support post H
L1 L1 8100.055 Stainless steel lateral support post with handle K 2
8100.056 A4 document holder J
Double shelf for SMD reel support L1 = 630mm 29 slits
8100.073 for side, pitch 20mm
K K
Double shelf for SMD reel support L1 = 1000mm49 slits
8100.074 for side, pitch 20mm M 3
8100.075P Divider for SMD reels N

M M N N

Z
L2 K K H H J J
L2
Load capacity: 250kg
Load capacity for single shelf: 50kg 8100.055 8100.054 8100.056

CHARIOTTE reel holder is designed to prepare and transport the SMD reels to the assembly area, and mainly to make the

replacement of empty reels on the automa c machines. The capacity of the trolley is 4 shelves for reel size 330mm and 5 shelves
for reel size 220mm. Steel shelves are adjustable in height , the mobile dividers help to compartmentalize the reels. Every shelf
is provided with labels.
TRESTON smd reel holder

The adjustable reel holder trolley is compa ble with SMD reels, and suitable for transport

and stocking of them. The trolley is in powder coated steel, RAL7035 ESD. The reel holder
is galvanized.

The trolley has four perforated steel shelves
depth 460mm. All shelves are individually
adjustable.
The load capacity of one shelf is 50kg, and the
load capacity of the trolley is 200kg.
7805.698
7805.698

8100.020 Trolley with four shelves and wheels (reel holders not included)
Dim. 1100 x 530 x 1780(H)mm
7805.698 Reel rack Ø 180 / 330 / 380mm - Dim. 960x426x254(H)mm 8100.020

1
0
Smd reel holder
3
1
8
4.
0
1
0
8104.012 8104.013
8
1
2
4.
0
(wire shelving page 54)
The Wire Reel Holders can be combined with the
standard wire shelves and posts. (see page 54)
8104.012 WIRE SHELF for 180mm SMD reels - 455x910x95(H)mm. Slot opening 16mm - Reel capacity /shelf: about 80
8104.013 WIRE SHELF for 330/380mm SMD reels - 455x910x108(H)mm. Slot opening 50mm - Reel capacity /shelf: about 13
