CHARIOTTE - Trolley per newbox

CHARIOTTE conduc ve trolleys are ideal for efficient handling of tote boxes,

circuit board carriers, cabinets and other parts handling containers.
The basic unit consist of two lateral support posts on a stable, wide based
assembly.

a a Steel shelves are adjustable in height, depth and lt angle.
1750 mm 300x400 boxes.

P370 shelf, without fi ngs, can accomodate one EURO 600x400 or two EURO

In the table below are listed the parts forming the trolley shown le .
code descrip on fi g. Qnt.
k 8100.050 Stainless steel baseplate with castors x 1
x
8100.054 Stainless steel lateral support post H
Stainless steel lateral post with handle K 2
8100.055
8100.056 A4 document holder J
760 mm 8100.065 P370 shelf 370x630mm a 6 in figure

NEWBOX tote boxes (cat. page 22)
8100.066 P600 shelf 600x630mm
Load capacity for single shelf: 50kg

Chariotte - trolley for laberack b c

CHARIOTTE conductive trolley can be customized to carry Printed
Circuit Boards or LABEFIX trays. The trolley shown in figure consists Load capacity for
of four LABERACK carriers, securely housed on the two special double single shelf: 50kg
support shelves.
In the table below are listed the parts forming the trolley shown
right:

codice descrip on fi g. Qnt.
8100.050 Stainless steel baseplate with conduc ve castors x 1
8100.054 Stainless steel lateral support post H
8100.055 Stainless steel lateral post with handle K 2
8100.056 A4 document holder J
8100.068 Double shelf for 2 LABERACK racks d 2 g d
7804.007 LABERACK wall c LABERACK
7804.017 LABERACK intermediate wall housing on shelf
LABERACK aluminium bar
7804.002 (600mm lenght) g

7804.021 LABERACK handle for transport (rail fixing) b rack 600 mm
x
pc board storage & transport LABECART

A mobile PCBs' store, ideal for transporting work process and storing

large quan es of board. Adjustable panels with horizontal slides feature
12,54mm (1/2”) spacing. Made by stainless steel structure and conduc ve
plastic panels. 84 slides per side, accepts boards or trays up to 9mm
thickness. Load capacity: 250kg
8104.312 Stainless steel lateral support post pair
8104.318 Stainless steel stud ∅ 25x1000mm (n.6 each cart)
8104.327 Side wall 1120x510mm / 84 rails
3 3
8104.325 Intermediate wall 1120x510mm / 84 rails each side
8104.330 Lower stainless steel shelf 660x1000mm
8104.695 ESD wheel kit, ∅ 125mm ( 2 with brake)
8104.696 NON-ESD wheel kit, ∅ 125mm ( 2 with brake)
