Dino-Lite special lighting -  infrared (IR)                                                      More information on www.dino-lite.eu/infrared




                                                                           Dino-Lite handheld microscopes with
                                                                           infrared light  or combinations between
                                                                           infrared and ultraviolet light.




                                                                            2   2-year
                                                                                European

                                                                                warranty
                                                                                Free SDK
                                                                                available for

                                                                                integration projects
                                                                                Wireless streaming
                                                                                in combination
                                                                                with WF-10 unit
                                                                                Regulatory
                                                                                approval:

                                                                                CE, FCC, ROHS
            AM4113xx series             AM7013xx series
                                                                                Included software:
                                                                                DinoCapture 2.0 (Windows),

                                                                                DinoXcope (Mac OS)




             MODE L               RESOLUTION   MAGNIFICATION  CONNECTIVITY  LONG WORKING   DISTANCE  MEASUREMENT  & CALIBRATION  NUMBER OF   LEDS  TYPE OF LEDS  EMISSION FILTER  EXCHANGABLE   CAPS  POLARIZER  METAL HOUSING  ESD SAFE  GENERATION  PRICE RANGE

             SPECIAL LIGHTING INFRARED
            AM4115-FKT        1,3 Megapixel  20-220x    USB 2.0  -     ✔     8          780 nm IR     ✔     ✔     -     -     -     Edge      € 500 - 600
            AM4115-FIT        1,3 Megapixel  20-220x    USB 2.0  -     ✔     8          850 nm IR     ✔     ✔     -     -     -     Edge      € 400 - 500
            AM4115-FJT        1,3 Megapixel  20-220x    USB 2.0  -     ✔     8          940 nm IR     ✔     ✔     -     -     -     Edge      € 400 - 500
            AD4113T-I2V       1,3 Megapixel  20-200x    USB 2.0  -     ✔     4+4  390/400 nm UV + 940 nm IR  ✔  ✔  -    -     -       -       € 300 - 400
            AM4115T-JV        1,3 Megapixel  20-220x    USB 2.0  -     ✔     4+4  390/400 nm UV + 940 nm IR  ✔  ✔  -    -     -     Edge      € 500 - 600
            AM7013M-FIT       5 Megapixel  10-70x, 200x  USB 2.0  -    ✔     8          850 nm IR     ✔     -     -    ✔     ✔        -       € 500 - 600
            AD7013MTL-FI2     5 Megapixel    20-90x     USB 2.0  ✔     ✔     8          940 nm IR     ✔     ✔     -    ✔     ✔        -       € 600 - 700
