TJ-70 / TJ-85

Hot Jet Nozzles

TJ-70 Hot Jet Tips

Tips Description Tip Size A x B Part Number

Small, Straight, Single Jet Tip 0.060" I.D. 1121-0366-P1

Small, Curved, Single Jet Tip 0.060" I.D. 1121-0338-P1

SOIC Tip (dual-jet) A = 4.32mm (0.17") 1121-0330-P1

A = 7.11mm (0.28") B = 1.88mm (0.074") 1121-0365-P1
Flat End Tip
A = 6.10mm (0.24") B = 1.88mm (0.074") 1121-0371-P1

TJ-85 Hot Jet Nozzles

Tips Description Tip Size Part Number

Round Nozzle 1.5mm (.06") Inner diameter 1259-0129-P1

Round Nozzle, Bent 60 degrees 1.5mm (0.6") Inner diameter 1259-0130-P1

6.1mm x 1.9mm (.24" x .074")
Flat Jet Nozzle 1259-0131-P1
Inner flow dimensions
