Soldering tips and nozzles | WRK Reflowset
WRK Reflowset Soldering Stations
Soldering iron and safety rest
WRK Reflowset
Reflow system for SMD components with external hot air - works with desoldering station WR 3M.
Soldering tips and nozzles
Order No. T005 15 155 99N
Accessory for 200 W Hot air station
Preheating plates
Reflow system with vacuum pick-up
For desoldering of SMD components 30 x 30 mm
Scope of supply Order No. Model Description Soldering bathes
T005 87 617 03 Tripod Pick-up Tripod Pick-up
T005 87 617 08 Pick-up 4,5 mm Vacuum Pick-up 4,5 mm
T005 87 617 09 Pick-up 10 mm Vacuum Pick-up 10 mm
T005 87 617 10 Reflow housing Reflow housing 33 x 33 mm
T005 87 617 11 Reflow housing Reflow housing 27 x 27 mm
T005 87 617 12 Reflow housing Reflow housing 24 x 24 mm Circuit board holder
T005 87 617 13 Reflow housing Reflow housing 20 x 20 mm
T005 87 617 14 Reflow housing Reflow housing 18 x 18 mm
T005 87 617 15 Reflow housing Reflow housing 15,5 x 15,5 mm
T005 87 617 16 Reflow housing Reflow housing 12,5 x 12,5 mm
T005 87 617 17 Reflow housing Reflow housing 10 x 10 mm
T005 87 617 25 Rack for nozzles Depositing rack for nozzles Solder feeder
Accessories Order No. Model Description
T005 15 154 99N Rack for Nozzles WRK Depositing rack for Nozzles
T005 87 137 98 Vacuum insert Ø 10 mm Vacuum insert Ø 10 mm
T005 87 137 99 Vacuum insert Ø 4, 5 mm Vacuum insert Ø 4,5 mm
T005 87 617 30N WRK Set Reflow housing set 24 x 24 mm, 27 x 27 mm Hot air heating gun
T005 87 617 31N WRK Set Reflow housing set 20 x 20 mm, 27 x 27 mm
T005 87 617 32N WRK Set Reflow housing set 10 x 10 mm, 12,5 x 12,5 mm, 15,5 x
15,5 mm, 18 x 18 mm
Temperature measuring
Accessories
