TROLLEYS Bin and cabinet trolleys

Cabinet trolley for storage cabinets

• Double-sided ESD-protected trolley for small-part storage cabinets
• Steel frame and fixed bottom shelf powder-coated with a
semiconductive ESD paint (light grey, RAL 7035).
• Maximum eight small-parts cabinets, 4 on each side, to be ordered
separately
• Four swivel ESD-castors (ø 100 mm), two with brakes.
• Module M750, all the upright tube accessories are available

Cabinet trolley BT-550B ESD
Name Size W x D x H mm Max load kg Code ESD
Cabinet trolley 780 x 715 x 1600 300 BT-550B ESD
Height of the fixing rails can be adjusted easily without tools. Height adjustable ergonomic push
handle.

Suitability
Type Number of drawers Dimensions W x D x H
551-4ESD 48 pcs 69 x 170 x 40
554-4ESD 24 pcs 92 x 170 x 62

Stacking bin trolley

• Double-sided ESD-protected trolley for stacking bins
• Steel frame and fixed bottom shelf powder-coated with a semiconductive ESD paint (light grey, RAL 7035).
• Up to 112 stacking bins can be attached to one trolley, must be ordered separately
• Height adjustable ergonomic push handle

• Sixteen step-by-step height adjustable bin rails, eight bin rails per side, length of bin rails 742mm
• Height of the bin rails can be adjusted easily without tools
• Four swivel ESD-castors (ø 100 mm), two with brakes
• Load capacity for bin rail 50 kg, for trolley 300 kg
• Module M750, all the upright tube accessories are available.

Trolley BT-170B ESD
Name Size W x D x H mm Max load kg Code ESD
Stacking bin trolley 780 x 715 x 1630 300 BT-170B ESD

Suitability
Stacking bin Quantity/rail Max. quantity/stand
1015 7 pcs 112 pcs
1520 5 pcs 80 pcs
1525 5 pcs 80 pcs
1930 4 pcs 64 pcs
