Light and balancer rail

All luminares are fitted to light/balancer rails which are
height and depth adjustable. Tool balancer rails and Width of the front profile 1500 mm
sliding pieces faciliate the use of heavy equipment. A tool
balancer is fixed to the light/balancer rail.

Light and balancer rail (includes one sliding hook)
Modular size Width of the front Max load kg Code
profile mm
2 x M500 1000 15 918 49 001P      Modular size M750
2 x M500/1500 1500 15 918 49 002P
4 x M500 2000 15 918 49 003P
M750 750 15 918 49 004P
M750/900 900 15 918 49 013P  Width of the front profile 1500 mm
M750/1500 1500 15 918 49 005P
2 x M750 1500 15 918 49 006P
3 x M750 2250 15 918 49 012P
M900 900 15 918 49 007P  
      
    
2 x M900 1800 15 918 49 008P      
   
  
M900/1500 1500 15 918 49 009P 

M1200 1200 15 918 49 010P
M1350 1350 15 918 49 011P Modular size 2 x M750
With extension benches you also need a center bracket, code 860 074-49.
Tool balancers and other supplies
Name Tool weight kg Code
Tool balancer 2DU 0,5 - 1 939 502-00
Tool balancer 4DU 1 - 2 939 503-00
Sliding piece with a snap hook 890 557-51 Tool balancer Sliding hook

Energy rails,

distributor for compressed air

Energy rails (brackets for uprights included)
Width mm fixing Code
1 2 4
1 440 8 sockets + on/off switch 910 51 001P
2 440 6 sockets + fault current protection 910 51 002P
3 M750 6 sockets + on/off switch 911 51 002P
M900 7 sockets + on/off switch 911 51 003P WORKBENCHES WORKSHOP and TP accessories
Bracket pair for perforated panel 853 185-51
Energy rails are available in three module sizes: M500, M750 and M900
(440 mm wide model suites module size M500 horizontally).

Distributor for compressed air
Connections, Ø 8 mm In Out Fixing Code
4 Distributor for compressed air 1 2 vert. 859 861-00
Connectors are compatible with the CEJN 3200 series. 3
Can be fitted to all Treston benches.

! For UK energy rails please contact
salesuk@treston.com for further details.
