Accessory frame for TP bench
Upright tubes or the upright tube module are always
attached to the TP bench with an accessory frame.
The accessory frame cannot be used on line or corner
extensions.

Bench frame Fixing points for uprights Code
width mm Accessories from page 24
1000 1 x M900 TPK10-49 ! TP bench with upright tubes can be equipped with the same
1200 1 x M750, 1 x M900, 1 x M1200 TPK12-49 accessories as Workshop bench.
1500 1 x M1500, 2 x M750 TPK15-49
1800 1 x M1800, 2 x M900 TPK18-49

Lower shelf for TP

Not enough space above the workstation? Then utilise the
space below. The lower shelf for TP bench simply hangs The TP bench can
on the horizontal bars. be fitted with a
lower shelf.

Name Size Max Code
W x D mm load kg
Lower shelf 1080 x 500 50 AT120 TPH
Lower shelf 1380 x 500 50 AT150 TPH
Lower shelf 1680 x 500 50 AT180 TPH

SAP trolley
Construction as TP bench. Height adjustment with allen
key between 650-900 mm. Swivel castors (Ø 100 mm),
two of which have brakes. Load capacity 150 kg. Lower
shelf, extra shelf and push handle available separately.

Name Size Max Code Code ESD
W x D mm load kg
Trolley 700 x 500 150 SAP507 SAP507 ESD
Trolley 1000 x 700 150 SAP710 SAP710 ESD
Trolley 1500 x 700 150 SAP715 SAP715 ESD SAP trolley with AT lower shelf and PUSH handle.
Lower shelf 700 x 500 40 AT507 AT507 ESD
Lower shelf 1000 x 700 40 AT710 AT710 ESD
WORKBENCHES TP and TPH
Extra shelf 700 x 500 40 LT507 LT507 ESD
Extra shelf 1000 x 700 40 LT710 LT710 ESD
Handle depth 500 PUSH50 PUSH50
Handle depth 700 PUSH70 PUSH70
