TPH workbench

310 mm

The TPH workbench already includes a pair of uprights
and one shelf; composing our best selling workstation 700 / 900 mm
set. It has its own range of accessories, also in stock, and
covering the essential, basic needs of any professional
workstation.

Height adjustment with allen-key between 650-900mm. 1080-1550 mm
Workbench with upright profiles and a laminate shelf. The
shelf has a height adjustment between 1080-1550mm
and a load capacity of 50kg. Construction as TP.

1200 / 1500 / 1800 mm
Workbench TPH
Bench size Shelf size Max Code Code ESD
W x D mm W x D mm load kg
1200 x 700 1200 x 310 300 TPH712 TPH712 ESD
1500 x 700 1500 x 310 300 TPH715 TPH715 ESD
1800 x 700 1800 x 310 300 TPH718 TPH718 ESD Accessories on page 30
1500 x 900 1500 x 310 300 TPH915 TPH915 ESD !
There is a large range of workbench accessories available.
1800 x 900 1800 x 310 300 TPH918 TPH918 ESD

Corner workbench TPH KK
TPH715* TPH707 KK TPH715* A corner workbench can be used with two TPH benches
(with one H-frame pair) to create a 90 °angle setup. TPH
KK unit consists of a worktop, two H-frames and a leg in the
middle. Front side 565 mm.

Bench size Max load kg Code Code ESD
W x D mm
1100 x 1100 150 TPH707 KK TPH707 KK ESD
* Workbench with one H-frame pair. 1300 x 1300 150 TPH909 KK TPH909 KK ESD

Power channels for TPH
Dims mm Suitable for Code Power channels for TPH
Profile 1058 TPH712 TJK120 Constructed from aluminium profile, this range of compact
Profile 1358 TPH715/ 915 TJK150 power channels provides power distribution for TPH
Profile 1658 TPH718/ 918 TJK180
Includes 3 x E1, E2 TPH715/ 915 TJK150 SET benches. Pre-assembled with a choice of components,
Includes 3 x E1, E2 TPH718/ 918 TJK180 SET ordered separately. The power channel is isolated from
Double socket E1 the workbench. 3 m cable is included. Aluminium profile
Switch E2 72 x 72 mm. All meet with CE requirements.
Automatic fuse 10 A E3
Automatic fuse / Fault current protection 10 A/30 mA E4 WORKBENCHES TP and TPH
Emergency-stop-switch E5
Data connector/shielded for Cat.6 cable E6

The finished TJK 150 SET and TJK 180 SET include 3 double sockets (E1)
and a switch (E2). (Other SETs are also available.)

! For UK energy rails please contact Power channel TJK
salesuk@treston.com for further details.
