Accessories for

Workshop and TP

Horizontal Straight bracket Corner bracket Upright tubes are the basic element for accessorising
tube
our industrial furnishings. Accessories are attached to
TP and Workshop benches with the aid of upright tubes
or a pre-assembled, upright tube module. The module
includes upright tubes, horizontal tube(s), corner bracket
pair and straight bracket (if module has more than one
Upright
h= horizontal tube). The upright tubes or the upright tube
tube
module are attached to the back of the TP bench with
l= accessory frame (ordered separately).

Upright tubes
Name Size mm Length Code
(l) mm
Upright tube 30 x 60 500 860 991-49
Accessory frame
Upright tube 30 x 60 800 860 142-49
Upright tube 30 x 60 996 860 367-49
Upright tube 30 x 60 1359 860 024-49
Upright tube 30 x 60 1582 860 025-49
Upright tube pair* 30 x 30 1219 854 038-49
* Used in the service trolley (page 48).

Horizontal tube M500 860 819-49
Horizontal tube M750 847 402-49
Horizontal tube M900 840 104-49

Corner bracket pair 848 336-49
Straight bracket 851 827-49

The modular (M) size refers to the distance between two Upright tubes and compatibility
WORKBENCHES WORKSHOP and TP accessories
upright tubes from the middle of the tube. The modular size is
used to find the appropriate accessories. Bench width
1000 1200 1500 1800 2000 2250
1 x M750 W TP W W W
1 x M900 W TP W W W
! Upright tube modules 1 x M1000 W TP
For TP Bench we recommend using upright modules which
1 x M1200
include horizontal bars. This increases the stability of the 1 x M1500 TP/W W W
uprights.
1 x M1800 TP W W
2 x M500 W W W W
2 x M750 TP/W W W
Upright tube modules for TP benches
2 x M900 TP W W
Suitable for bench widths Code Code 2 x M1000 W
l =1359 mm l =1582 mm 3 x M500 W W W
1200 1500 1800
3 x M750 W
1 x M750 TP 900 49 001P 900 49 002P
4 x M500 W
1 x M900 TP 901 49 001P 901 49 002P
W = Workshop
2 x M750 TP 903 49 001P 903 49 002P
2 x M900 TP 904 49 001P 904 49 002P
Load capacity 100 kg / module spacing.
