accessories for WB workbench

5. Bin profile BP

Aluminium profile for TRESTON stacking and picking bins. Mount
on accessory frame.

Code Dims mm Suitable for 6 7
BP 70 ESD length 685 WB 815/818 ESD 8 9

BP 100 ESD length 985 WB 811/818 ESD

6. Perforated panel ARL

Perforated steel panel with 9 mm perforations at 38 mm centres.
Mount on accessory frame with screws.

Code Dims mm Suitable for
ARL 70 500 x 685 WB 815/818 ESD
ARL 100 500 x 985 WB 811/818 ESD

7. Support bracket HSB

Support bracket of steel for suspending power tools and lighting
units. Mount on upright profiles.

Code Length mm Suitable for

HSB 110 1073 WB 811 ESD
HSB 150 1500 WB 815 ESD
HSB 180 1800 WB 818 ESD

8. Swivel arm with tray AKV 10 11
12
Lockable, angle adjustable steel tray with swivel radius of 360°.

Length of swivel arm 590 mm. Semiconductive epoxy powder
coated steel. Max. load 15 kg.

Code Tray mm Suitable for

AKV 400 ESD 210 x 460 WB ESD

9. Keyboard shelf WKA 13
Keyboard shelf with swivel arm. Semiconductive epoxy powder
coated steel. Load capacity 15 kg. Arm length 220 mm.

Code Shelf mm Suitable for

WKA ESD 220 x 500 WB ESD Kuvassa CJK 70 SET

10. Document stand WDA 15

Document stand A3 with swivel arm. Semiconductive epoxy 14
powder coated steel. Arm length 220 mm. Tilt 75°.

Code Stand mm Suitable for
WDA ESD 440 x 300 WB ESD

11. Cable tidy WBCT 14. Bottle holder CH

Mount on leg frame. A cable tidy is standard equipment on Practical holder for bottle or cup. Made of black polypropylene. Inside diameter 80
motor and retractable handle bench mm. Outside dimensions: D x W x H: 110 x 105 x 120 mm.

Code Dims mm Suitable for 15. Power channels

WBCT 110* 64 x 204 x 948 WB 811 ESD May be fitted with a choice of components, ordered separately. All meet with CE
requirements. 3 m cable is included. Supplied wired and ready for use. A finished CJK
WBCT 150 64 x 204 x 1375 WB 815 ESD 70 SET includes 3 double sockets (E1) and a switch (E2).
WBCT 180 64 x 204 x 1675 WB 818 ESD (Other SETs are also available.)

12. Lower shelf AT-WB
Height adjustable lower shelf, 26 mm ESD-laminate. Load
capacity 50 kg. Mount between aluminium profiles. Code Dims mm Suitable for

Code Dims mm Suitable for CJK 70 profile 631 WB 815/818
AT 110 WB ESD * 400 x 828 WB 811 ESD
CJK 100 profile 931 WB 811/818

AT 150 WB ESD * 400 x 1255 WB 815 ESD CJK 70 SET 3 double sockets (E1) and a switch (E2)
AT 180 WB ESD * 400 x 1555 WB 818 ESD
COMPONENTS

E1 Double socket

13. Cable clip set CC E2 Switch

The cable clip set will hold cables etc. securely and neatly E3 Automatic fuse 10 A
in place along the bench frame. The clips locate in the 8 mm
profile slot. E4 Automatic fuse/earth leakage switch 10 A/30 mA

E5 Emergency-stop-switch

E6 Data connector/shielded for Cat.6 cable

Code Set Suitable for E7 Data connector/without screen for Cat.5 cable

CC8 5 pieces AL2X E8 Pneumatic, quick coupling 3/8”

*) To order 7
