accessories for WB workbench

1. Upright profiles AL2X-W 1
12
Needed for mounting accessories to benches. Includes 2 vertical
and 1 horizontal profile. With 3 cable clips (CC8). 3

Code Dims mm Suitable for 4
AL2X 110 W 1063 x 900 WB 811 5

AL2X 150 W 1489 x 900 WB 815
AL2X 180 W 1789 x 900 WB 818

The upright profiles are attached 2. Accessory frame AKK
to the workbench frame through
the worktop. The accessory frame divides the space between the upright profiles
into 2 modules. AKK frame includes 1 vertical and 1 horizontal
profile. Useable height 500 mm.

Code Dims mm Suitable for

AKK 150 690 + 690 WB 815

AKK 180 690 + 990 WB 818

Accessories 3. Shelf ALH

Steel parts are epoxy powder Height adjustable shelf, 26 mm ESD-laminate. Load capacity 50 kg.
coated light grey paint, RAL Mount on upright profiles.
7035. Shelves are of 26 mm ESD-
laminate. Code Dims mm Suitable for

Suitability: ALH 110 ESD 310 x 1073 WB 811
• WB 811 ESD benches
ALH 150 ESD 310 x 1500 WB 815
can be fitted with size 100
accessories in one module ALH 180 ESD 310 x 1800 WB 818
• WB 815 ESD benches can be
fitted with size 70 accessories 4. Adjustable shelf ASH
in two modules
• WB 818 ESD benches with Continuous adjustment for depth, height and angle. Shelf of 26 mm
one size 70 and one size 100 ESD-laminate. Lipped front edge. Load capacity 35 kg static load.
module. Mount on accessory frame.

Code Dims mm Suitable for

ASH 70 ESD 400 x 660 WB 815/818

ASH 100 ESD 400 x 960 WB 811/818
