Spacemisers for small parts
storage cabinets

Thousands of sensitive components and other parts
can be kept in proper order using an ESD-protected
spacemiser. The assembly holds 12 small parts storage
cabinets.
Owing to its robust base and divider shelf system, the
spacemiser retains its cabinets firmly in place and has a
load capacity of 400 kg. Mounted on a ball-bearing
base, the unit can be effortlessly rotated for ease of use. A
single assembly can offer storage for up to 3456 different
items on a floor area of only 0.25 sqm. Earthing via a 1
megaohm protective resistor. The unit is easy to assemble.

Spacemiser 12-550 ESD

• This assembly holds 12 storage cabinets from series
551/554 ESD (ordered separately).

• This unit includes a ball-bearing base, shelves in three
layers and a lid.

• Load capacity 400 kg
• Dimensions W x D x H: 500 x 500 x 1730 mm
• Ground-connection cord included.

Bench top spacemiser PTP-5 ESD

This unit holds two small parts storage cabinets, 290 mm
or 550 mm in height, with their backs facing each other
— cabinets must be ordered separately. The assembly
comprises a ball-bearing base and a bottom plate.
Includes a ground-connection cord. Load capacity 50 kg.
The overall dimensions of a completely assembled unit,
W x D x H:
360 x 310 x 300 mm (291/294 ESD)
360 x 310 x 560 mm (551/554 ESD)
