5 5. Stacking bins
6
*) Made to order. Request a quotation. Made of semiconductive polypropylene (PP). Dividers coated with a semiconductive ESD
paint and labels with protective covers as an accessory. Labels and protective covers are
not conductive.

Code External dimensions Capacity, Quantity, Cross divider Labels + shields
W x D x H mm litres package (ordered (ordered

separately) separately)

1015-4ESD 105 x 165 x 75 0.6 60 — E-10
1520-4ESD 149 x 192 x 105
1525-4ESD 149 x 250 x 130 1.5 45 — E-15
1930-4ESD 186 x 300 x 156
1940-4ESD 186 x 400 x 156 2.7 30 V-14 E-15
1950-4ESD* 186 x 510 x 182
3040-4ESD* 310 x 400 x 156 5.0 24 V-19 E-20
3050-4ESD* 310 x 500 x 182
7.2 24 V-19 E-20

9.6 12 V-195 E-20

11.9 12 V-30 E-20

17.8 8 V-30 E-20

6. Containers

Two volumes: 18 and 36 litres. They have integrated handles and stack securely together.
Material is semiconductive polystyrene (PS).

Code External dimensions Capacity, Quantity,
W x D x H mm litres package
10-18L-4ESD
10-36L-4ESD 323 x 535 x 150 18.0 4
323 x 508 x 280 36.0 3

Stacking bin trolley

Trolley BT-170B ESD

• Double-sided ESD-protected trolley for stacking bins
• Steel frame and fixed bottom shelf powder-coated with a semiconductive ESD paint (light grey, RAL 7035).
• Up to 112 stacking bins can be attached to one trolley, must be ordered separately
• Four different sizes of stacking bins to choose from
• Height adjustable ergonomic push handle
• Sixteen step-by-step height adjustable bin rails, eight bin rails per side, length of bin rails 742mm
• Height of the bin rails can be adjusted easily without tools
• Four swivel ESD-castors (ø 100 mm), two with brakes
• Load capacity for bin rail 50 kg, for trolley 300 kg
• External dimensions W x D x H: 780 x 715 x 1630 mm
• Module M750, all the upright tube accessories are available.

Suitability Quantity/rail Max. quantity/stand
7 pcs 112 pcs
Stacking bin 5 pcs 80 pcs
1015 5 pcs 80 pcs
1520 4 pcs 64 pcs
1525
1930
