Stacking bin racks

1 x stacking bin rack BR-2530, 1 x stacking bin rack BR-4050,
35 x red stacking bin 1930-5 30 x grey stacking bin 1940-3

Bin rack BR-2530 Bin rack BR-4050

On BR racks, stacking bins are inclined at a 20-degree This product includes a grey steel frame in an epoxy
angle, enabling the excellent presentation of products. powder-coated finish and six fixed, forward-sloping
They offer an efficient storage system for daily use when storage levels, 930 mm in width. Stacking bins must be
small components are required frequently. This product ordered separately.
includes a grey steel frame in an epoxy powder-coated
finish and seven fixed, forward-sloping storage levels, 930 Load capacity 50 kg per level and 350 kg per rack.
mm in width. Stacking bins must be ordered separately. Overall dimensions W x D x H: 990 x 600 x 1670 mm.

Load capacity 50 kg per level and 350 kg per rack. Suitability
Overall dimensions W x D x H: 990 x 500 x 1540 mm.
Stacking bin
Suitability Quantity/rail pair Max. quantity/rack 1940 Quantity/rail pair Max. quantity/rack
6 pcs 42 pcs 1950 5 pcs 30 pcs
Stacking bin 5 pcs 35 pcs 3040 5 pcs 30 pcs
1525 3050 3 pcs 18 pcs
1930 3 pcs 18 pcs

Gravity flow rack DBS-808 1 x gravity flow rack DBS-808,
48 x stacking bins 1940-6
This rack is suitable for retail, manufacturing and
warehousing. On a two-bin gravity flow rack, loading
and unloading takes place on opposite sides of the rack.
Items are picked up from the front bin. Through the force
of gravity, the rearmost bin slides all the way down to the
front edge of the rack once the empty bin is removed. This
product includes a grey steel frame in an epoxy powder-
coated finish and six detachable, steel shelves, positioned
at an angle. The shelf height and gradient are adjustable.
Adjustable feet are provided for fine levelling of the rack on
uneven surfaces. Easy to install. The rack holds 48 stacking
bins from series 1940, to be ordered separately.

Load capacity is 70 kg per shelf and 420 kg per rack.
Shelf dimensions: 755 x 700 mm.
Overall dimensions W x D x H: 830 x 825 x 1650 mm
Castor set is available.
