EBP BARS

• Earth Bonding Point Bars (common ground points) designed
Benchware & Field Service
to be mounted on under-side of bench top or shelf
• Supplied with screws and spare ring terminal, black
cord 3m long, exits via strain relief on right
• Fitted with three 1 Megohm (1x10E6 ohms) 1/2 Watt resistors
• Made in Britain

Part No. Description
231271 EBP Bar with 3 x 10mm Studs, Grey
231270 EBP Bar with 3 x 10mm Studs, Grey, No Resistor
231275 EBP Bar with 3 x 10mm Studs, Yellow
231288 EBP Bar with 2 x 10mm Studs,
1 x 4mm Plug Socket, Grey
231296 EBP Bar with 2 x 4mm Plug 231271
Sockets, 1 x 10mm Stud, Yellow
231305 EBP Bar with 3 x 4mm Plug Sockets, Yellow
Download Technical Drawing 231270
Check out our selection
of coiled cords,

wristbands and mats

SLIM EBP BARS
• Slim Earth Bonding Point Bars (common
ground points) designed to fit underneath
bench tops with narrow overhang >16mm
• 3 x 1 Megohm (1x10E6 ohms) 1/2 Watt
resistors fitted (except 231350)
• Made of yellow ABS with welded back
cover, 110mm x 16.5mm x 37mm
• Made in Britain
Part No. Description
231345 Slim EBP with 3 x 10mm Studs
231350 Slim EBP with 3 x 10mm Studs, No Resistor
231360 Slim EBP with 3 x 4mm Studs 231345
Download Technical Drawing 231345

EBP BOXES
• Earth Bonding Point (common ground points)
Boxes designed to be mounted on bench
• Black cord 3m long, can exit towards left or right
• 1 Megohm (1x10E6 ohms) 1/2 Watt resistor for each connector
• Made in Britain
Part No. Description
231390 EBP Box with 3 x 10mm Studs
231395 EBP Box with 3 x 10mm Studs, No Resistor 231390
231400 EBP Box with 3 x 4mm Plug Sockets
231380 EBP Box with 2 x 4mm Plug Sockets, 1 x 10mm Stud
231385 EBP Box with 2 x 4mm Plug Sockets, 1 x 10mm Stud, No Resistor
Download Technical Drawing 231390

See our products being
