EARTH FACILITY BRACKETS

            •  Serves as a grounding hub for earth bonding points
              (common ground points), can receive several wires
            •  Supplied with mounting screws - easy to mount
            •  Strain relief built in
            •  Size: 40mm x 45mm x 12mm
            •  Made in Britain
                                                                             231425
            Part No.  Description
            231425   EF Bracket with M5 Binding Post, No Resistor
            231420   EF Bracket with Insulated Binding Post, No Resistor
            Download Technical Drawing 231420


                Check out the set-up
                    of a typical EPA                                                                                  Benchware & Field Service




            EBP BRACKETS

            •  Earth Bonding Point (common ground points)
            •  Brackets can be fixed to wall or bench
            •  Black cord 3m long, can exit top or bottom
            •  Size: 40mm x 45mm x 12mm                                           231405
            •  Made in Britain
            Part No.  Description
            231405   EBP Bracket with 10mm Stud,
                    1 Megohm (1x10E6 ohms) Resistor
            231410   EBP Bracket with 10mm Stud,
                    2 Megohms (1x10E6 ohms) Resistor
            231415   EBP Bracket with 10mm Stud, No Resistor
            Download Technical Drawing 231405




            EARTH BONDING POINT PLUGS

            •  Provide safe and low-cost path to electrical mains earth
            •  Fits UK 13A socket or European Schuko socket
            •  Made of yellow, impact-resistant ABS plastic             231225          UK Plug            Euro Plug
            •  1 Megohm  (1x10E6 ohms) 1/2 Watt resistor
              built in to each stud connector
            •  Made in Britain
            Part No.  Description
            231180   UK Plug with 1 x 4mm Stud, 2 x 10mm Studs
            231200   UK Plug with 3 x 10mm Studs
            231230   UK Plug with 2 x 4mm Plug Sockets, 1 x 10mm Studs
            231195   UK Plug with 1 x 10mm Stud, No Resistor
            231185   UK Plug with 1 x 10mm Stud
            231225   UK Plug with 1 x 2BA Binding Post, No Resistor
            231135   European Plug, 3 x 10mm Studs
            231125   European Plug, 1 x 4mm / 2 x 10mm Studs
            231170   European Plug, 2 x 4mm Plug Sockets, 1 x 10mm Stud
            Download Technical Drawings 231135 and 231180
                                                                        231230                            231195
                                                                                         231200
